Help CenterYT24 Air Leg Rock Drill
Related Products
Specifications
YT24 air drill is widely used for blasting holes and other drilling projects in a quarries, railway construction.YT24 Air leg Rock Drill is suitable for drill level or gradient holes in medium hard or hard rock(f=8-18).The drilling depth can be five-eight meters. It can be matched with the FT140BD short air-leg or FT140B long air-leg to use in the basis of the width of rock.Also it can be fixed on drilling-vehicle or drilling-shelf.
To ensure the well lubricating.This rock drill may match FY200B oil reservior .
Specification
Weight 24 kg
Length 678mm
Cylinder dia 70mm
Piston stroke 70mm
Air pressure 0.40.63MPa
Impact frequencey ≥ 31Hz
Air consumption ≤66.7 L/S
Air pipe (inner dia) 19mm
Water pipe (inner dia) 13mm
Shank head dia 34-42mm
Shank dimensions(hex*length) 22*108 mm
