Quick Details
- Condition: New
- Type: Wheel Tractor
- By wheel: 4WD
- Usage: Farm Tractor
- Certificate: CE
- Brand Name: YJF
- Model Number: LW-6/7/8
- Place of Origin: Shandong, China (Mainland)
- Colour: black, red, blue
- CE certificate: Self oil tank, pump
- Increasing speed gear: Wheel Tractor
- Condition: New
- Usage: Farm Tractor
- By wheel: 4WD
- Match type: PTO driven backhoe
Packaging & Delivery
| Packaging Details: | iron crate |
|---|---|
| Delivery Detail: | 20days after getting the deposit |
Specifications
1) john deere backhoe loader
2) LW-6/7/8/9/10,
3) With self oil tank, pump
4) With increasing speed gear
5) CE certificate
Parameters of john deere backhoe loaderAll are with self hydraulic pump, oil tank, increasing speed gear box, handed control valve, and luxury spring seat andsafety belt.
Model |
LW-6 |
LW-7 |
LW-8 |
|||||||
Max. digging depth (mm) |
1850 |
2150 |
2640 |
|||||||
Max. digging radius (mm) |
2800 |
3360 |
3930 |
|||||||
Max. digging height (mm) |
2500 |
3400 |
3510 |
|||||||
Loading height (mm) |
1400 |
1760 |
2000 |
|||||||
Max. digging depth (2ft) Flat bottom (mm) |
1600 |
2000 |
2500 |
|||||||
Digging Length(mm) |
1610 |
1410 |
1450 |
|||||||
Knighthead expanding width |
1800 |
1830 |
1820 |
|||||||
Swing Arc (°) |
140 |
160 |
140 |
|||||||
Bucket rofation (°) |
160 |
160 |
160 |
|||||||
Size (m3)Standard attached |
0.036 |
0.045 |
0.054 |
|||||||
Cap. (mm)Standard attached |
300 |
400 |
450 |
|||||||
Overall dimension |
2300×1860×890 |
2360×1960×1270 |
2500×1960×1400 |
|||||||
Weight(kg) |
470 |
540 |
600 |
|||||||
Valve standard press |
16Mpa |
16Mpa |
16Mpa |
|||||||
Valve over loading protect press |
7±1MPa |
7±1MPa |
7±1MPa |
|||||||
Valve input flux area |
12~28L/mm |
12~28L/mm |
12~28L/mm |
|||||||
Connect height (mm) |
410 |
460 |
460 |
|||||||
Connect width (mm) |
399 |
H′=530 |
H′=530 |
|||||||
Up connect pinhole Dia. |
φ22 |
φ22 |
φ22 |
|||||||
Down Connect pinhole Dia. |
φ19 |
φ19 |
φ19 |
|||||||
Bucket standard |
Cap. (mm) |
250 |
300 |
400 |
450 |
500 |
550 |
|||
Size (m3) |
0.030 |
0.036 |
0.045 |
0.054 |
0.060 |
0.066 |
||||
