Help CenterYT27 Air-Leg Rock Drill
Related Products
Specifications
YT27 Air-Leg Rock Drill used for blasting holes and other drilling works in a quarries, railway construction.item name:YT27 Air-Leg Rock Drill
Specification
Weight 27 kg
Outside dimension(L×W×H) 668×248×202mm
Cylinder dia 80mm
Piston stroke 60mm
Impact energy ≥75.5J
Impact frequencey ≥ 36.7Hz(2202bpm)
Air consumption ≤83.3L/S(4.998m3/min)
Air pipe (inner dia) 25mm
Water pipe (inner dia) 13mm
Air pressure 0.63MPa
Water pressure 0.3MPa
Bore dia 34-45mm
Bore depth 5m
Shank dimensions(hex×length) 22×108±mm×mm
The rock drill is a kind of high efficiency air leg rock drill machine.It is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and national defence project facility.
When it is matched with Model FY250 Oil reservoir and Model FT160A or FT160B Air-leg , it is suitable for wet drilling under various of rocks at aclinic and incline orientation,it can also use in the trolley without Air-leg.
