Home > Lights & Lighting > LED Encapsulation Series > SMD LED > LED SMD 5050 RGB Light Source CE,RoHS Certification China Supplier
LED SMD 5050 RGB Light Source CE,RoHS Certification China Supplier
US$ 0.01 - 0.02
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Model Number:
EL-5050RGB
Chip Material:
Other, Gold wire
Emitting Color:
Tri-Color(Red-Blue-Green)
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Brightness 0.5W 5730 Smd Led SpecificationsUS$ 0.01 - 0.15MOQ: 1000 Pieces -
LED Diode Light Source LED SMD 3528 Smd LedUS$ 0.01 - 0.02MOQ: 1000 Pieces
-
3528/3014/5630/3014/2838 5050 SMD LEDUS$ 0.01 - 0.015MOQ: 1000 Pieces
-
Light Source Ultra Brightness 3014 SMD LEDUS$ 0.005 - 0.01MOQ: 2000 Pieces
-
SMD LED 335 Light for Led Module,stripUS$ 0.008 - 0.03MOQ: 1 Piece
Model Number
EL-5050RGB
Chip Material
Other, Gold wire
Emitting Color
Tri-Color(Red-Blue-Green)
Luminous Intensity
4500mcd
Luminous Flux(lm)
15lm
Optical Attenuation(%)
0.3
Power
0.1W
Power Dissipation
0.1
Color Rendering Index(Ra)
85
Color Temperature
4000
Operating Temperature(℃)
-40, 85
Storage Temperature(℃)
-40, 85
Place of Origin
China
Brand Name
EXCELIGHTS
Certification
CE
5050 LED SMD Diode Light Source
Product Description
1.Specifications for 5050 LED SMD
1. Light color: RGB
2. Intensity: 4500-5000mcd
3. Dimmensions: 5.0*5.0mm
4. Beam Angle: 120 degree
5. Forward current: 60mA
6. Forward voltage: 3.0-3.2V
7. Operating temperature: -40 to +85°C
8. Storage temperature: -40 to +100°C
9. Package: 1000pieces/reel
2.Features for 5050 LED SMD
1. Extremely wide viewing angle
2. Available on tape and reel
3. Suitable for all SMT assembly and solder process
4. Moisture sensitivity level: level 4
5. High CRI
6. With re-flow soldering technology
7. High consistency in light color, high cost-effective
3. Applications for LED SMD
1. Optical indicators
2. Indoor displays
3. Interior automotive lighting
4. Backlight for LCDs, switch and symbols and displays
5. Light pipe applications
6. Used for LED Strips, LED Modules, LED Tubes and LED Spot lights.
