Cost-efficient ,high-quality air
With its state-of-the-art oil-free compressor technologies such as screw, tooth , centrifugal, reciprocating and scroll, Atlas Copco provides the right solutions for your specific needs. As oil-free compressed air is a prerequisite for many manufacturing processes, we ensure consistent oil-free air by preventing oil from entering your compressed air system.
The SF and SF+ ranges of oil-free scroll air compressors unite Atlas Copco’s vast experience and knowledge in a class-leading package .whereas the SF range includes a standard pneumatic controller, the SF+ range boasts the high-end elektronikon controller. Reliable and compact ,they both answer your demands through innovative technologies and supreme energy efficiency without compromising on quality.
SMARTLink
•Remote monitoring system that helps you optimize your
compressed air system and save energy and costs.
•Provides a complete insight in your compressed air network.
•Anticipates on potential problems by warning you up-front.
PURE OIL-FREE AIR
As there is no metal-to-metal contact between the compression
Scrolls , there is no need for oil lubrication in the compression
chamber. Therefore, the scroll compression principle guarantees
high-quality, oil-free air. As a result, the SF compressor is
oil-free in every way.
ENERGY EFFICIENCY
The SF scroll compressors, standard equipped with IE3
Premium efficiency motors, are suited for sensitive applications
which require flexibility and energy efficiency. Unloaded power
consumption is eliminated thanks to the simple start/stop
control. Advanced scroll technology guarantees an optimal free
air delivery and low duty cycle applications.
EXTREMELY LOW NOISE LEVEL
The slow speed of the scroll compression elements ensures that
the SF scroll compressors are extremely quiet. Sound levels are
as low as 53 dB(a), making the SF the perfect choice for your
sensitive working environment.
SIMPLICITY AND RELIABILITY
The SF scroll compressors stand for simplicity and reliability.
The compressor has a minimal number of moving parts,
ensuring a long operating life with limited service interventions.
With their integrated design, Atlas Copco’s SF scroll
compressors have a minimal footprint and offer
easy serviceability.
PROVEN PEACE OF MIND
For over sixty years, Atlas Copco has been leading the industry
in oil-free compressed air technology, drawing on vast
experience and continuous technological innovations. You can
rest assured at all times: severe certification and testing
procedures are conducted to ensure air is supplied to the
highest standards of quality control.
ADVANCED SCROLL TECHNOLOGY
Solid efficiency is a distinctive advantage of the Atlas Copco SF series, thanks to the unique working principle
of scroll technology. Air compression is achieved by the interaction of a fixed and orbiting scroll. Air at inlet
pressure enters the compression chamber at the exterior side of the scroll element. Once air is drawn in, the
orbiting scroll seals off the inlet port. As the scroll continues to orbit, the air is progressively compressed
into an increasingly smaller ‘pocket’. A continuous flow of compressed air leaves the scroll element through
a discharge port in the center of the fixed scroll. This process is continuously repeated, resulting in the delivery
of pulse-free compressed air.
WORKPLACE AIR SYSTEM™ COMPRESSORS:
THE SOUND OF SILENCE
Atlas Copco WorkPlace Air System™ compressors are much more than low noise air compressors with
integrated air treatment equipment. To help you save energy and costs, they are designed to give the most efficient source of compressed air within a production environment.
Quiet and compact
A low noise level enables the compressor to
be installed close to the compressed air
application, minimizing the size of the air
distribution system and reducing pressure
loss and the potential for leakage.
A solution that fits
Thanks to the broad range of Atlas Copco air
treatment technology, you can select the
most efficient system to meet your specific
compressed air requirements.
Cost-saving
As the air treatment is completely integrated,
the installation costs are substantially
reduced, making multiple compressor
installations practical and financially viable.
Supreme energy efficiency
To ensure maximum energy efficiency,
Atlas Copco offers both traditional on/off
regulating systems where the air demand
is constant.
Peace of mind
With the SF, Atlas Copco does not just
offer the most reliable and efficient
compressors. From air quality
solutions to a complete piping
installation, Atlas Copco can take
responsibility of your entire
compressed air system to provide you
with best-in-class air. Choose from a
wide range of Atlas Copco after sales
products and services that will have
your SF performing at its best for
years to come. Qualified Atlas Copco
support is available in over
180 countries.
| TYPE | Max working pressure | Capacity FAD# | Installed motor power | Noise level## | Weight | |||||
| bar(e) | psig | l/s | m³/min | cfm | kw | hp | dB(A) | kg | lbs | |
| SF1-6/2+_6+(50/60HZ) | ||||||||||
| SF1 | 8 | 116 | 2.9 | 0.17 | 6.1 | 1.5 | 2 | 53 | 120 | 265 |
| 10 | 145 | 1.9 | 0.11 | 4 | 1.5 | 2 | 53 | 120 | 265 | |
| SF2/SF2+ | 8 | 116 | 4.2 | 0.25 | 8.9 | 2.2 | 3 | 55 | 125 | 276 |
| 10 | 145 | 3.4 | 0.20 | 7.2 | 2.2 | 3 | 55 | 125 | 276 | |
| SF4/SF4+ | 8 | 116 | 6.7 | 0.40 | 14.2 | 3.7 | 5 | 57 | 133 | 293 |
| 10 | 145 | 5.9 | 0.35 | 12.5 | 3.7 | 5 | 57 | 133 | 293 | |
| SF6/SF6+ | 8 | 116 | 9.8 | 0.59 | 20.8 | 5.5 | 7.5 | 59 | 157 | 346 |
| 10 | 145 | 7.6 | 0.46 | 16.1 | 5.5 | 7.5 | 59 | 157 | 346 | |
| SF8+_22+(50/60HZ) | ||||||||||
| SF8+ | 8 | 116 | 13.4 | 0.80 | 28.4 | 8 | 10 | 63 | 485 | 1070 |
| 10 | 145 | 11.4 | 0.68 | 24.2 | 8 | 10 | 63 | 485 | 1070 | |
| SF11+ | 8 | 116 | 20.3 | 1.22 | 43 | 11 | 15 | 63 | 515 | 1135 |
| 10 | 145 | 15 | 0.90 | 31.8 | 11 | 15 | 63 | 515 | 1135 | |
| SF15+ | 8 | 116 | 26.4 | 1.58 | 55.9 | 15 | 20 | 63 | 580 | 1280 |
| 10 | 145 | 23 | 1.38 | 48.7 | 15 | 20 | 63 | 580 | 1280 | |
| SF17+ | 8 | 116 | 31 | 1.86 | 65.7 | 17 | 22 | 64 | 595 | 1315 |
| 10 | 145 | 23.7 | 1.42 | 50.2 | 17 | 22 | 64 | 595 | 1315 | |
| SF22+ | 8 | 116 | 40.8 | 2.45 | 86.5 | 22 | 30 | 65 | 680 | 1500 |
| 10 | 145 | 30 | 1.80 | 63.6 | 22 | 30 | 65 | 680 | 1500 | |
| SFD11+_22+50/60Hz | ||||||||||
| SFD11+ | 8 | 116 | 9.8 | 0.59 | 20.8 | 11 | 15 | 63 | 625 | 1380 |
| 10 | 145 | 7.6 | 0.46 | 16.1 | 11 | 15 | 63 | 625 | 1380 | |
| SFD15+ | 8 | 116 | 13.4 | 0.80 | 28.4 | 15 | 20 | 64 | 755 | 1665 |
| 10 | 145 | 11.4 | 0.68 | 24.2 | 15 | 20 | 64 | 755 | 1665 | |
| SFD 22+ | 8 | 116 | 19.2 | 1.21 | 42.8 | 22 | 30 | 65 | 840 | 1855 |
| 10 | 145 | 15 | 0.90 | 31.8 | 22 | 30 | 65 | 840 | 1855 | |
| SF SKID/TWIN | ||||||||||
| Skid versions | ||||||||||
| SF 1 | 8 | 116 | 2.9 | 0.17 | 6.1 | 1.5 | 2 | 65 | 105 | 232 |
| 10 | 145 | 1.9 | 0.11 | 4 | 1.5 | 2 | 65 | 105 | 232 | |
| SF2 | 8 | 116 | 4.2 | 0.25 | 8.9 | 2.2 | 3 | 67 | 110 | 243 |
| 10 | 145 | 3.4 | 0.20 | 7.2 | 2.2 | 3 | 67 | 110 | 243 | |
| SF4 | 8 | 116 | 6.6 | 0.40 | 14 | 3.7 | 5 | 68 | 120 | 265 |
| 10 | 145 | 5.6 | 0.34 | 11.9 | 3.7 | 5 | 68 | 120 | 265 | |
| Twin versions | ||||||||||
| SF 6T | 8 | 116 | 10.6 | 0.64 | 22.5 | 5.9 | 8 | 72 | 365 | 805 |
| 10 | 145 | 9 | 0.54 | 19.1 | 5.9 | 8 | 72 | 365 | 805 | |
| SF 8T | 8 | 116 | 13.2 | 0.79 | 81.1 | 7.4 | 10 | 73 | 375 | 827 |
| 10 | 145 | 11.2 | 0.67 | 68.8 | 7.4 | 10 | 73 | 375 | 827 | |
| DIMENSIONS | ||
| L*W*H | ||
| MM | INCH | |
| SF1-6/2+_6+ | ||
| Pack&floor-mounted | 760*690*840 | 29.9*27.2*33.1 |
| Full Feature &floor-mounted | 1025*690*840 | 40.4*27.2*33.1 |
| Pack&2701 receiver | 1275*690*1450 | 50.2*27.2*57.1 |
| Full Feature &2701 receiver | 1275*690*1450 | 50.2*27.2*57.1 |
| Pack&5001 receiver | 2055*690*1450 | 80.9*27.2*57.1 |
| Full Feature &500l receiver | 2055*690*1450 | 80.9*27.2*57.1 |
| SF8+_22+ | ||
| SF8+_11+ | 1670*750*1230 | 65.729.5*48.4 |
| SF15+_22+ | 1628*750*1844 | 64.1*29.5*48.4 |
| SF11+_22+ | ||
| SF11+_22+ | 1628*750*1844 | 64.1*29.5*48.4 |
| SF1-4Skid/SF6-8Twin | ||
| SF1-4Skid FM | 800*600*540 | 31.5*23.6*21.3 |
| SF1-4Skid TM | 1267*600*1154 | 19.9*23.6*45.4 |
| SF 6-8 Twin | 2043*600*1154 | 80.4*23.6*45.4 |
