hd Peephole Viewer ( Support PIR Motion Detecting)

Item

Digital  Door Camera

Remarks

Machine Part

Indoor unit size

138mm*103mm*25mm

Outdoor unit size

18mm*Dia.50mm

Adapter plate

100mm*78mm*9.5mm

Ambient light adaptation

Working environment

Illumination of the outdoor unit

20 lux~3500 lux

Resolution

The resolution of images on the indoor monitor should not be less than 200 (Central level, under800 lux condition)

MIC part

Capacitive Electret

Microphone

Diameter 6MM Height: 2.7MM

Sensitivity: 40 + /-3dB

Camera Part

Camera Pixel

Width:640, Height:480

300K Pixel

Camera Angle

Diagonal:115+/-5 degrees

Horizontal:102+/-3 degrees

Vertical: 85+/-3 degrees

Digital Zoom

3X digital zoom

Loudspeaker Part

Loudspeaker

Diameter: 20MM Power: 1W

Impedance: 8 OHM

Display Screen

Display Type

240(R+G+B)*320 Dots

LCD Type

2.8 inch TFT LCD

Viewing Direction

6 O”colock

Backlight

4 LED white color

water-proof dust-proof requirements

Indoor Unit: IP30;

Outdoor Unit: IP33

Installation Part

Door Thickness suited

Door thickness is: 35mm-55mm,55mm-85mm and 85mm-105mm.

Can be customized so that fit for any thickness of the door

Door peephole size

Dia.15mm

Memory

Own memory

256M

Memory Extension

Maximum support 32G SD card and backward compatible

Power Part

Battery Charger

(MODEL:VA8B-050100)

Input: 110 V to 240 V 50/60 Hz, 0.3 A

Output: Dc 5.0 V 1.0A

5.0V

Battery Pack

(lithium-ion)

(MODEL:DS-L600)

Voltage/capacity: 3.7 V, 1800 mAh

Clock battery

Dia.20.0 thick:3.2 3.0V CR2032

Infrared mobile monitoring

Distance

Near: <1.5M ; Far: <2.5M

Working Condition

Ambient temperature

-10 °C~+55 °C;

Relative Humidity

10 %~95 %;

Atmospheric pressure

86 kPa~106 kPa

Others

Include SD card or not

Optional according to customer’s request

Include battery

Include 1pc 1800mAh lithium battery

Language

Kinds of language to set

Settings function

time and date settings function

Sleep automatically

Can automatically go to sleep

File save format

JPEG,MP4
