GYXTY8S special optical fiber cable
structure : PBT for the middle-casing, and 12 (or 10, 8) high-strength steel (or sets of plastic steel wire) strands in uniform-casing around, outsourcing non-woven fabrics and steel - bonded polyethylene jacket , and with the Strand (or wire) parallel 8 fonts placed at the same time squeezing into cable sheathing. | |||||||||||||||||
quantity of fibers:2~12 | |||||||||||||||||
outer diameter(mm):10.5- | |||||||||||||||||
approximated cable weight(kg/km):170- | |||||||||||||||||
Laying mode:Aerial | |||||||||||||||||
operating temperature:-40°C~+60°C | |||||||||||||||||
|
Application: Long distance and interoffice communication
| |||||||||||||||||
The main mechanical properties: |
Allow tensile force(N) |
short-term |
1500 |
||||||||||||||
long-term |
600 |
||||||||||||||||
Allow squash Force(N/100mm) |
short-term |
1000 |
|||||||||||||||
long-term |
300 |
||||||||||||||||
min bend radius(D:ODmm) |
Static |
10D |
|||||||||||||||
Dynamic |
20D |
||||||||||||||||
Wooden drum
Incore Terms:
USD $1-$5000: EXW
USD $5001-$10000: FCA
Above USD $10000: FOB
Certification:
Hongkong Exhibition Show:
| FACTORY INTRODUCTION: |
|
Our factory, HAIYAN HUXI WIRE&CABLE CO.,LTD ,was found in 1995,we specialize in designing and manufacturing cable products for 18 years with good quality and pretty competitive price,Especially the CAR WIRING KITS,SPEAKER CABLE,RCA CABLE,HDMI CABLE etc.And we do OEM for customers with reliable quality.More infos for our company,please link: |
| WORKSHOP SHOW: |
