Home > Products > Surface pump > 2CPM25/160A double impeller small water pump
2CPM25/160A double impeller small water pump
- 10000 Piece / Pieces per Month
- Ningbo or Shanghai
- T/T
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | unipompe OEM | Model Number: | 2CPM25/160A |
Theory: | Centrifugal Pump | Structure: | Multistage Pump | Usage: | Water |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, electric |
Pressure: | High Pressure | Application: | Other, irrigation |
Product Description
2CPM25/160A double impeller small water pump
RANGE OF PERFORMANCE
8Flow rate up to 250 l/min (15 m3/h)
8Head up to 70m
LIMITS OF USE
8Manometric suction lift up to 9m
8Liquid temperature up to +60°C
8Environment temperature up to +40°C
INSTALLATION AND USE
8These pumps are suitable for handling clean water without abrasive particles and liquids that are chemically non-aggressive to the pump components. Reliable, economical and simple to use, they are suitable for domestic use and in particular for distributing water in combination with small pressure sets, for irrigating gardens. The pumps must be installed in a covered area, protected against the inclement weather.
MOTOR
8Two –pole induction motor (n=2850rpm)
8Insulation Class B
8Protection grade IP44
MATERIALS
8Pump body: Cast iron, with threaded opening ISO 228/1.
8Motor support: Cast iron
8Motor housing: Aluminum
8Impeller: Brass
8Shaft with rotor: Carbon steel or stainless steel
8Mechanical seal: Ceramic/ Graphite
8Bearing: NSK, C&U, or local quality.
Technical Parameters
MODEL | POWER | MAX.FLOW | MAX.HEAD | INLET/OUTLET | MAX.SUCT | G.W | PACKING SIZE | ||
1Phase | 3 Phase | (Kw) | (Hp) | (L/min) | (m) | (Inch) | (m) | (K.g) | (mm) |
2CPM25/130 | 2CP25/130 | 0.75 | 1 | 90 | 44 | 1 1/4"*1" | 8 | 15 | 265*130*160 |
2CPM25/140M | 2CP25/140M | 1.1 | 1.5 | 160 | 47 | 1 1/2"*1" | 8 | 20.5 | 265*130*160 |
2CPM160/160 | 2CP160/160 | 1.5 | 2 | 125 | 66 | 1 1/4"*1" | 8 | 25 | 265*130*160 |
2CPM25/160A | 2CP25/160A | 2.2 | 3 | 200 | 68 | 1 1/2"*1" | 8 | 27 | 265*130*160 |
2CPM32/200C | 2CP32/200C | 3 | 4 | 250 | 70 | 1 1/2"*1 1/4" | 8 | 40 | 265*130*160 |
Three-phase 220/380V-50Hz (60hz), single phase 220V/60Hz, 110V/60Hz, 127V/60Hz & 110V/220V/60Hz are available on request.
