250W Sanisplit Macerator Pump, best sanivort pump Quality Choice

Specifications

sanisplit macerator pump 3 inlets + 1 outlet
sanivort pump
sewage lifting unit
head 6~7 m
CE&GS

HMAC-250 SERIES MACERATOR PUMPS FOR SEWAGE LIFTING





WORKING PRINCIPLE:

Sanisplit macerator is a twin sectioned box with a built-in macerator pump that automatically grinds and discharges water (up to 100° C), acid and grease water, body waste and toilet paper, originating from either the bathroom or the kitchen, through a small 32 or 40 mm diameter pipe into the nearest sewer or soil stack.

Sanisplit is a multi-purpose product solution for any application. Complete with blanking caps suitable for 1 sink or complete bathroom, kitchen, toilet



APPLICATIONS:

8Bathrooms
8Basement installations
8Renovation of offices and other commercial buildings
8Wash basins, bath tubs
8Washing machines and dishwashers in basement below sewer level
8Where the location may be remote from the main soil pipe so that a natural slope cannot be established.



FEATURES:

8Compact and slim for easy integration into the wall
8Unique design with smooth line and rounded edges-fits every modern bathroom environment
8Low noise level, good waterproof performance and suitable for installation
8The tank is made of light plastic material with an easy-to-clean surface
8Automatic (semi-automatic) start and stop
8The tank is vented through a carbon filter in the vent valve in the top cover
8Discharge pipe connection in the side ensures easy maintenance
8Flexible discharge pipe adapters for outer pipe dimeters



PUMPED LIQUIDS:

This pump is suitable for wastewater from a washbasin and sewage water form a toilet containing toilet paper and faeces
8Max.Liquid temperature: 35°C
8Max.Ambient temperature: 40°C
8The pump can also be used for ordinary liquids for cleaning of the units connected
8PH value: 4 to 10
8The pump must not be used for strong chemicals or solvents



Permance table:
