Swimming Pool Roof Solar Collector

Specifications

Swimming Pool Roof Solar Collector :

Manifold: Stainless Steel 304
Structure/Stand: SS or Hot galvanized spray painted
Reflector: Stainless Steel
Horizontal Angle: 30 /20/25/45degree
Nipple s (Inlet & Outlet): 1" SS
Height: 1.40m A+/- 0.03m
Tube Type: Vacuum Glass Tube (Open/Closed)
Dia: 47/58mm
Length: 1500/1800mm

Insulation: Insulation with 100mm glass wool and cladding with 24 SWG Al.
Application: Vacuum tube solar collectors are amongst the most efficient and most costly types of solar collectors. These collectors are best suited for moderate temperature applications where the demand temperature is 50-95C and/or for very cold climates. Applications of vacuum tube collectors include heating of domestic and commercial hot water, buildings, and indoor swimming pools. Due to their ability to deliver high temperatures efficiently another potential application is for the cooling of buildings by regenerating refrigeration cycles.

 Item Number

170-47/1500-48

170-47/1500-50

170-47/1500-60

170-58/1800-48

170-58/1800-50

170-58/1800-60
