Single Copper Coil Solar Water Heating

FOB Price

USD $30 - $650 / Set

1 Set(Min.Order)

Supply Ability 100000 Set / Sets per Month
Port SHANGHAI
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Evacuated Tube	Pressure	Unpressurized
Circulation Type	Direct / Open Loop (Active)	Heating System	Thermosyphon (Passive)
Connection Type	Direct-Plug	Installation	Freestanding
Housing Material	Stainless Steel	Certification	CE, CE, Other, CE, CE, ISO9001-2000,SRCC ,SGS ,solar keymark
Capacity	190	Place of Origin	Jiangsu, China
Brand Name	SUNNERGY, SUNNERGY	Model Number	SN SERIES

Product Description

Specifications

Single Copper Coil Solar Water Heating
high effeciency
5 years quality warranty
OEM available
CE ISO9001-2000 SRCC CE SGS

Single Copper Coil Solar Water Heating

Changzhou sunnergy solar water heater co., ltd .is specially engaged in research ,development ,production and sales of solar water heaters and collectors and solar water tanks.

Product name:	evacuated tube solar water heater
Product size:
Product class:	Unpressurized Type
Product Introduction:

Stainless Steel System:

1. Material of Inner tank: SUS304-2B stainless steel with 0.4mm thickness

2. Material of Outer tank: SUS304-2B stainless steel with 0.31mm thickness

3. Magnetic-controlled Al-N-Al splash all glass evacuated heat-collecting tubes, fast heat absorbing and temperature risen

4. Heat Preservation Layer:55mm polyurethane integral foaming, superior heat preservation

5. Material of support:Stainless Steel Profiled Bar with 1.2mm thickness

Model	Absorbing Area (m2)	Glass Vacuum Tube			Tank Capability (L)	Loading Qty(sets) 20"/40"
Model	Absorbing Area (m2)	Ø(mm)	L(mm)	NO.(PCS)	Tank Capability (L)	Loading Qty(sets) 20"/40"
420-1500/47-15-C	0.75	47	1500	15	85	66/137
420-1500/47-18-C	0.90	47	1500	18	100	56/115
420-1500/47-20-C	1.00	47	1500	20	111	50/105
420-1500/47-24-C	1.20	47	1500	24	135	44/92
420-1500/47-30-C	1.50	47	1500	30	166	36/75
470-1500/47-15-C	0.75	47	1500	15	113	51/102
470-1500/47-18-C	0.90	47	1500	18	140	44/88
470-1500/47-20-C	1.00	47	1500	20	150	42/84
470-1500/47-24-C	1.20	47	1500	24	180	33/66
470-1500/47-30-C	1.50	47	1500	30	230	30/60
470-1800/58-16-C	1.28	58	1800	16	133	44/91
470-1800/58-18-C	1.44	58	1800	18	150	39/81
470-1800/58-20-C	1.60	58	1800	20	165	35/73
470-1800/58-24-C	1.92	58	1800	24	200	30/62
470-1800/58-30-C	2.40	58	1800	30	250	24/50
