Ralink 802.11n Wireless Lan Card Rohs Pci Card Drivers

US$ 7 - 9 MOQ: 1000 Pieces

Key Specifications

Products Status:

Stock

Application:

Desktop

Type:

Wireless

Shenzhen Dcom Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Desktop

Type Wireless

Kind Internal

Transmission Rate Other, 150Mbps

Interface Type PCI

Certification CE,FCC,ROHS

Brand Name OEM

Model Number DWP-N115R

Place of Origin Guangdong, China

Specifications

wifi adapter data card
1.wireless pci adapter lan card,150Mbps
2.Easily connect to network, to surf internet
3.PCI Interface

wifi adapter data card

Software Specification
Standards	IEEE802.11n,IEEE 802.11g, IEEE 802.11b
Wireless Signal Rates With Automatic Fallback	11n:Up to 150Mbps(Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic)
Frequency Range	2.4 GHz
Output Power	18dBm
Modulation Type	1M DBPSK, 2M DQPSK, 5.5M/11M CCK, 6M/9M/12M/18M/24M/36M/48M/54M OFDM
Receiver Sensitivity	54M:-68dBm@10% PER 11M:-85dBm@8% PER 6M:-88dBm@10% PER 1M:-90dBm@8% PER 256K:-105dBm@8% PER
Work Mode	Ad-Hoc Infrastructure
Wireless Security	64/128/152 bit WEP WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Support Operating System	Windows 7(32/64bits), Windows Vista(32/64bits), Windows XP(32/64bits), Windows 2000
*:EIRP-total effective radiated power is 100dBm(100mW), antenna gain will not influence wireless transmit power

Hardware Specification
Interface	32-bit PCI connector
Antenna	2dBi Detachable Omni-directional Antenna (Reverse SMA Connector)
Certifications	CE, FCC
Operating Temperature	0°C~40°C (32°F~104°F)
Storage Temperature	-40°C~70°C (-40°F~158°F)
Relative Humidity	10% ~ 90% non-condensing
Storage Humidity	5%~95% non-condensing
Dimensions	5.2 × 4.8 × 0.9 in. (133 × 121 × 22 mm)
