Wireless Networking Device Pci Lan Adapter

US$ 7 - 9 MOQ: 1000 Pieces

Key Specifications

Products Status:

Stock

Application:

Desktop

Type:

Wireless

Shenzhen Dcom Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Desktop

Type Wireless

Kind Internal

Transmission Rate 54Mbps

Interface Type PCI

Certification CE,FCC,ROHS

Brand Name OEM

Model Number DWP-G541R

Place of Origin Guangdong, China

Specifications

1.wireless networking device pci lan adapter
2.Easily connect to network, to surf internet
3.PCI Interface
4.802.11b/g 54mbps

wireless networking device pci lan adapter

Software Specification
Standards	IEEE 802.11g, IEEE 802.11b
Wireless Signal Rates With Automatic Fallback	11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic)
Frequency Range	2.4 GHz
Output Power	18dBm
Modulation Type	1M DBPSK, 2M DQPSK, 5.5M/11M CCK, 6M/9M/12M/18M/24M/36M/48M/54M OFDM
Receiver Sensitivity	54M:-68dBm@10% PER 11M:-85dBm@8% PER 6M:-88dBm@10% PER 1M:-90dBm@8% PER 256K:-105dBm@8% PER
Work Mode	Ad-Hoc Infrastructure
Wireless Security	64/128/152 bit WEP WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Support Operating System	Windows 7(32/64bits), Windows Vista(32/64bits), Windows XP(32/64bits), Windows 2000
*:EIRP-total effective radiated power is 100dBm(100mW), antenna gain will not influence wireless transmit power

Hardware Specification
Interface	32-bit PCI connector
Antenna	2dBi Detachable Omni-directional Antenna (Reverse SMA Connector)
Certifications	CE, FCC
Operating Temperature	0°C~40°C (32°F~104°F)
Storage Temperature	-40°C~70°C (-40°F~158°F)
Relative Humidity	10% ~ 90% non-condensing
Storage Humidity	5%~95% non-condensing
Dimensions	5.2 × 4.8 × 0.9 in. (133 × 121 × 22 mm)
