85m Homeplug Powerline Ethernet Bridge

85m Homeplug Powerline Ethernet Bridge thumbnail-1
85m Homeplug Powerline Ethernet Bridge photo-1
US$ 43 - 45 MOQ: 500 Sets
Key Specifications
Get Latest Price
Brand Name:
OEM
Model Number:
DPL-W201B
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Shenzhen Dcom Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name OEM
Model Number DPL-W201B
Place of Origin Guangdong, China

Specifications

1.200M Powerline Wireless 11n AP
2.Wallmount type
3.Up to 200 Mbps Phy rate
4.85m homeplug powerline ethernet bridge

Parameter
Specification
PLC Module SPEC
Chipset
Intellon INT6400/INT1400
Serial Flash
16Mbits
SDRAM:
128Mbits
Firmware
Support North America/Europe/APAC/Japan
Protocol
HomePlug AV, Co-exists with existing HomePlug 1.0
IEEE 802.3 10/100 Ethernet (100Mbps)
IEEE 802.3u Fast Ethernet
PLC Rate
200Mbit/s
Data Rate - TCP/UDP
65Mbps TCP
90Mbps UDP
Modulation Band
2-30MHz
Modulation Schemes
Supports 1024/256/64/16/8-QAM, QPSK,BPSK and ROBO
Encryption
128-bit AES
QoS
Support contention-free access, four-level priority based contention access, and multi segment bursting
Support VLAN Priority
Support ToS and CoS Packet Classifier
Work Mode
TDMA and priority based CSMA/CA
Multicast Support
Supports IGMP managed multicast sessions
WiFi Module SPEC
Chipset
Ralink RT3050
Protocol
IEEE 802.11b/g/n
Wireless rate
11n:Up to 150Mbps
11g: Up to 54Mbps
11b: Up to 11Mbps
Wireless Frequency Range
2.4GHz to 2.484GHz
Modulation Type
For 802.11b (DSSS)
For 802.11g (OFDM)
For 802.11n (OFDM)
multi-BSSID
Up to 8 BSSIDs
Work mode
1Tx/Rx
Security
WPA, WPA2, 64/128/152-bit WEP, SSID hide,
MAC Address Access Control List
QoS
Support WMM, WMM-PS, MAC filter, Broadcast storm control and traffic control
System SPEC
System Support
Windows 98SE, 2000, ME, XP 32/64 bit and Vista 32/64bit
LED’s
Power/run: double color
PLC: double color, indicator PLC Link and Activity
WLAN: indicator Wireless Link and Activity
WPS: indicator the status of WPS Authenticator.
LAN: indicator the Ethernet Link and Activity
Power Socket
Support British, Euro, Japan, US and China power connector
Ethernet Interface
1x RJ45 for 10/100 Ethernet (Auto MDI/MDI-X)
Push Button
Reset: reset system or restore default setup
NMK: use to synchronized network password in PLC
WPS: use to authenticated for wireless provide service
Software update
Support software update from WEB
Consumption
7W (Typed)
Environment Requirement
Operating Temperature
0º to 40º C
Storage Temper

100-240 VAC, 50/60Hz
EMC and Safety
Regulatory Compliance
FCC Part 15 Class B, CE
Safety Regulations
UL
Green Standard
RoHS, WEEE
Physical Dimension
Physical Characteristics
L×W×H: 112mm×86mm×46mm
Weight
279g
ature
-20 º to 70 º C
Operating Humidity
10% to 85% Non-condensing
Storage Humidity
5% to 90% Non-Condensing
Input Rating
100-240 VAC, 50/60Hz
EMC and Safety
Regulatory Compliance
FCC Part 15 Class B, CE
Safety Regulations
UL
Green Standard
RoHS, WEEE
Physical Dimension
Physical Characteristics
L×W×H: 112mm×86mm×46mm
Weight
279g
