Specifications
1.Reliable Quality & Reasonable Price2.Top Performance & Long Life
3.Energy-saving & Cost-effective
4.CE, UL
5.USA Brand
PSC 24V dc brushless Blower with UL & CE for Solar Inverters and Wind Power Inverters -------PSCMF MOTOR & FAN INC.
Company profile
PSC Motor and Fan is an American company specialized in Thermal Solution since 1993, and its main products are DC/AC/EC Impeller, Centrifugal Fan, Axial Fan, Blower and CPU Cooler.
PSC has been a major supplier to HP Compaq, IBM, ATI, Cisco Systems, and Rockwell Automation, APC (American Power Conversion, SGI , Flextronics and other many well-known companies in the world.
Key Features
–HP-force
The new HP-force fans with their extremely high blower capacity of up to 950 m3/h and pressure build-up of up to 1200 pascals are capable of dealing with the extreme heat load. If needed, these fans can produce up to 100% more output under full load and they work with a much broader delivery bandwidth than current models. This makes them ideal for equipment and systems with a high density of components. Thanks to intelligent motor features, they can be individually adapted for any application.
The HP-force series is the most powerful product series on the market. HP-force stands for the highest innovation in motor technology, fluid mechanics and electronics. The one-of-a-kind power density of the products requires special attention to the application at the customer's facility.
– Compact dimensions
– Wide selection of models, dimensions and air performance levels
– Optimum efficiency and noise level due to well-engineered aerodynamic design of the fan blades
– High-efficiency, energy saving
– High reliability and service life
– Wide range of accessories, including guard grilles, basket guard grilles and wall rings
– Wide variety of monitoring and control functions enable customer oriented and demand-oriented fan operation
– Various protective mechanisms against ambient influences such as dust, humidity, water and salt
– The axial fan is dynamically balanced in two planes to DIN ISO 1940
– Numerous approvals, including VDE, UL, CUL and CE
– Applications: Ventilation, air-conditioning and refrigeration technology, automotive industry,
wind power and mechanical engineering/finishing equipment industry
Outline Drowing & base paremeter
| Model | Bearing System | Rated Voltage | Operating Voltage Range | Rated Current | Rated Speed | Maximum Air Flow | Maximum Static Pressure | Sound Level | Weight |
| Part NO. | B / S / F | V | V | A | RPM | CFM | mm-H2O | dBA | g |
| BGE07530_12J | BS | 12 | 7.0~13.2 | 0.09 | 2,600 | 10.90 | 7.80 | 32.1 | 100 |
| BGE07530_24J | BS | 24 | 14.0~26.4 | 0.04 | 2,600 | 10.90 | 7.80 | 32.1 | 100 |
| BGE07530_12L | BS | 12 | 7.0~13.2 | 0.15 | 3,000 | 12.70 | 9.10 | 41.4 | 100 |
| BGE07530_24L | BS | 24 | 14.0~26.4 | 0.12 | 3,000 | 12.70 | 9.10 | 41.4 | 100 |
| BGE07530_12M | BS | 12 | 7.0~13.2 | 0.25 | 3,600 | 17.00 | 12.20 | 47.5 | 100 |
| BGE07530_24M | BS | 24 | 14.0~26.4 | 0.22 | 3,600 | 17.00 | 12.20 | 47.5 | 100 |
| BGE07530_12H | BS | 12 | 7.0~13.2 | 0.42 | 4,000 | 21.40 | 15.70 | 51.3 | 100 |
| BGE07530_24H | BS | 24 | 14.0~26.4 | 0.30 | 4,000 | 21.40 | 15.70 | 51.3 | 100 |
| BGE07530_12U | BS | 12 | 7.0~13.2 | 0.45 | 4,600 | 22.50 | 20.20 | 53.0 | 100 |
| BGE07530_24U | BS | 24 | 14.0~26.4 | 0.40 | 4,600 | 22.50 | 20.20 | 53.0 | 100 |
