Home > Products > DC Axial Fan > PSC DC Axial flow fan:25*25*10mm 12v with CE & UL forData Center - Evaporative Cooling
PSC DC Axial flow fan:25*25*10mm 12v with CE & UL forData Center - Evaporative Cooling
- 20000 Piece / Pieces per Month
- HongKong
- T/T L/C D/P D/A Credit Card
Product Details
Electric Current Type: | DC | Mounting: | Other, computer/ ventilation | Blade Material: | Plastic |
Place of Origin: | Guangdong, China | Brand Name: | PSCMF, PSCMF | Model Number: | AGE02510B12U |
Voltage: | 12V | Power: | 1.44W | Air Volume: | 2.41CFM |
Speed: | 13000rpm | Certification: | CCC, CE, CSA, ROHS, UL, Other, CCC, CE, CSA, ROHS, UL, CUL, VDE | After-sales Service Provided: | Overseas service center available |
Product Description
PSC DC Axial flow fan : 25*25*10mm 12v with CE & UL forData Center - Evaporative Cooling ---------PSCMF MOTOR & FAN INC.
Company profile
PSC Motor and Fan is an American company specialized in Thermal Solution since 1993, and its main products are DC/AC/EC Impeller, Centrifugal Fan, Axial Fan, Blower and CPU Cooler.
PSC has been a major supplier to HP Compaq, IBM, ATI, Cisco Systems, and Rockwell Automation, APC (American Power Conversion, SGI , Flextronics and other many well-known companies in the world.
Key Features
–HP-force
The new HP-force fans with their extremely high blower capacity of up to 950 m3/h and pressure build-up of up to 1200 pascals are capable of dealing with the extreme heat load. If needed, these fans can produce up to 100% more output under full load and they work with a much broader delivery bandwidth than current models. This makes them ideal for equipment and systems with a high density of components. Thanks to intelligent motor features, they can be individually adapted for any application.
The HP-force series is the most powerful product series on the market. HP-force stands for the highest innovation in motor technology, fluid mechanics and electronics. The one-of-a-kind power density of the products requires special attention to the application at the customer's facility.
– Compact dimensions
– Wide selection of models, dimensions and air performance levels
– Optimum efficiency and noise level due to well-engineered aerodynamic design of the fan blades
– High-efficiency, energy saving
– High reliability and service life
– Wide range of accessories, including guard grilles, basket guard grilles and wall rings
– Wide variety of monitoring and control functions enable customer oriented and demand-oriented fan operation
– Various protective mechanisms against ambient influences such as dust, humidity, water and salt
– The axial fan is dynamically balanced in two planes to DIN ISO 1940
– Numerous approvals, including VDE, UL, CUL and CE
– Applications: Ventilation, air-conditioning and refrigeration technology, automotive industry,
wind power and mechanical engineering/finishing equipment industry
Basic Character
Major Characteristic Parameters | |||||||||
Model | Bearing System | Rated Voltage | Operating Voltage Range | Rated Current | Rated Speed | Maximum Air Flow | Maximum Static Pressure | Sound Level | Weight |
Part NO. | B / S / F | V | V | A | RPM | CFM | mm-H2O | dBA | g |
AGE02510_05U | BS | 5 | 4.4-5.5 | 0.22 | 13,000 | 2.41 | 7.30 | 28.0 | 7 |
AGE02510_12U | BS | 12 | 6.0-13.8 | 0.12 | 13,000 | 2.41 | 7.30 | 28.0 | 7 |
AGE02510_05H | BS | 5 | 4.4-5.5 | 0.16 | 10,000 | 1.85 | 4.40 | 23.5 | 7 |
AGE02510_12H | BS | 12 | 6.0-13.8 | 0.08 | 10,000 | 1.85 | 4.40 | 23.5 | 7 |
AGE02510_05M | BS | 5 | 4.4-5.5 | 0.13 | 7,000 | 1.32 | 1.90 | 20.0 | 7 |
AGE02510_12M | BS | 12 | 6.0-13.8 | 0.07 | 7,000 | 1.32 | 1.90 | 20.0 | 7 |
AGE02510_05L | BS | 5 | 4.4-5.5 | 0.12 | 6,000 | 0.88 | 1.40 | 18.0 | 7 |
AGE02510_12L | BS | 12 | 7.0-13.2 | 0.06 | 6,000 | 0.88 | 1.40 | 18.0 | 7 |
*Function type is optional. | *All reading are typical values at rated voltage | *Specifications are subject to change without notice | |||||||
* Bearing system B: Two Ball Bearing F: Fluid Bearing S: Sleeve Bearing |
