DC Centrifugal Fan Motor

DC Centrifugal Fan Motor thumbnail-1
DC Centrifugal Fan Motor photo-1
Negotiable MOQ: 200 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Electric Current Type:
Other, DC, DC
Mounting:
Other, heat exchanger/ventilations, Other
Blade Material:
Other, Plastic, Plastic
Contact Supplier Request Quote Chat Now
PSC Motor And Fan China Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type Other, DC, DC
Mounting Other, heat exchanger/ventilations, Other
Blade Material Other, Plastic, Plastic
Place of Origin Guangdong, China
Brand Name PSCMF, PSCMF
Model Number PF4820070LB2M
Voltage 48 V
Power 110.5
Air Volume 517.7 CFM
Speed 4600 RPM
Certification Other, UL CE, UL CE

Specifications

1.200x70mm DC Axial-Flow Fan
2.Rated Voltage:24/48V
3.Rated Speed:4600/2900RPM
4.PSC-The No 2 DC Fan Supplier

A200x70mm DC Axial-Flow Fan/xial-Flow Fan/DC Axial Radial Fan/Axial DC Fan



  1. size Ø200 x70mm
  2. Weight: 1.76kg
  3. Impeller: Plastic PA6.6(polyamide glass-fibre reinforced)
  4. Motor: DC brushless external rotor motor
  5. Rotor: Black paint
  6. Lead Wire: AWG#20 UL 1007
  7. Insulation: Class A
  8. Safety: UL.CE
  9. Operation Temperature:-20°c~+60 °c



Listed
Model		 Bearing
System		 Rated Voltage Operating Voltage Rated
Current		 Rated
Speed		 Power Air
Flow		 Air
pressure		 Noise
Level		 Available Features (Optional)
Part NO. B / S VDC VDC A RPM W CFM m3/h mmH2O inH2O dBA Tachometer
Output		 Autorestart Pulse Width
Modulation
PF2420070HB2M B 24 16~28 4.50 4,600 108.0 517.7 879.5 67.6 2.66 85
PF4820070HB2M B 48 36~56 2.30 4,600 110.4 517.7 879.5 67.6 2.66 85
PF4820070LB2M B 48 36~56 0.75 2,900 36.0 319.1 542.1 31.4 1.24 58
