DC Axial Impeller

DC Axial Impeller thumbnail-1
DC Axial Impeller photo-1
Negotiable MOQ: 200 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Electric Current Type:
DC
Mounting:
Other, heat exchanger/ ventilations
Blade Material:
Plastic
Contact Supplier Request Quote Chat Now
PSC Motor And Fan China Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type DC
Mounting Other, heat exchanger/ ventilations
Blade Material Plastic
Place of Origin Guangdong, China
Brand Name PSCMF, PSCMF
Model Number AGE25489_24L
Voltage 24V
Air Volume 552 CFM
Speed 1300 RPM
Certification CE

Specifications

1.254 DC Axial Impeller
2.PSC-The No 2 DC Fan Supplier
3.Lead time :shortly
4.price:Competitive

Axial Impeller/254x89mm DC Axial Impeller/Axial DC Small Impeller/Axial Fan



 DC Axial ImpellerDC Axial ImpellerDC Axial ImpellerDC Axial Impeller

General Specifications:

  1. Size: 254 x 89 mm
  2. Motor: 4 pole brushless DC motor
  3. Frame: Aluminum alloy
  4. Impeller : Thermoplastic PBT+15%GF(94V-0).
  5. Bearing: Precision ball bearing/sleeve bearing.
  6. Storage temperature : -40 °c ~ +75 °c
  7. Operating temperature : -10 °c~ +70°c



Listed
Model		 Bearing
System		 Rated
Voltage		 Operating
Voltage		 Rated
Current		 Rated
Speed		 Air
Flow		 Air
pressure		 Noise
Level		 Available Features (Optional)
Part NO. B / S / F V V A RPM CFM mm-H2O dBA Tachometer
Output		 Autorestart Speed Control
PF4825489UB2M B 48 28~56 1.9 3100 890.0 30 69
PF4825489HB2M B 48 24~55.2 1.3 2000 725.0 18 62
PF4825489MB2M B 48 24~55.2 1.0 1700 545.0 12 58
PF4825489LB2M B 48 24~55.2 0.7 1400 421.7 8.17 56
PF2425489HB2M B 24 12~26.5 2.0 2000 725.0 18 62
PF2425489MB2M B 24 12~26.5 1.5 1700 545.0 12 58
PF2425489LB2M B 24 12~26.5 1.2 1400 421.7 8.17 56
