Continuous Hanging Chain Shot Blasting Machine For LPG Cylinder
US$ 30,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Dongheng
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hanging Chain Shot Blasting Machine For LPG Cylinder Made in QingdaoUS$ 30,000 - 80,000MOQ: 1 Set -
CE Pipe Rollers Cleaning Machine for Cylinder Shot Blasting MachineUS$ 30,000 - 80,000MOQ: 1 Set
-
CE LPG Gas Cylinders Shot Blasting MachineUS$ 30,000 - 80,000MOQ: 1 Set
-
Hanger Type Shot Blasting Machine for Cleaning Gas Cylinder and Oxygen SurfaceUS$ 30,000 - 80,000MOQ: 1 Set
-
RELIABLE MANUFACTURE Shot Blasting Machine for Lpg CylinderUS$ 30,000 - 80,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
Dongheng
Model Number
QSW series
Feature
Critical Cleaning / Residue Free, Non-Toxic, Rust / Corrosion Inhibitor
Fuel
Electric
Certification
Other, ISO9001
Use
Burnishing, Container / Bottle Cleaning, Descaling / Stripping
Cleaning Process
Other, abrasive/grits/sand/shot
Cleaning Type
Other, abrasive/grits/sand/shot
Industry Used
Other, machinery, foundry, forging, mechanical and steel industry
Material
Metal / Coil
Power(W)
Depend
Dimension(L*W*H)
depend
After-sales Service Provided
Engineers available to service machinery overseas
CYLINDER TYPE SHOT BLASTING MACHINE
Product Description
Q6915 steel plate pass through type sandblast machine
Machine details:
- Blast wheels for outstanding speed without sacrificing coverage.
- Perfect for moving Steel fabrication to the blast chamber by conveyor rolls
- Wide range of machine types for different production rates and work pieces of different sizes
- High production rates, high blast cleaning performance
- Economical abrasive consumption. With 3 classes full flow curtain hammer style abrasive reclaim system. The abrasive media is cleaned and recycled, reducing disposal and minimizing abrasive costs.
- The number and power of the turbines are chosen according to the requirement production rate.
- PLC control system, stable quality and easy to get support from local.
- Sweden Standard descaling effect
- Switzerland +GF+DISA technology blast abrator
- Steel plate blast cleaning machine adopt PLC auto control and manual control method
Auto-detection, auto-alarm and auto-cutout. Alarm system adopts audible and visual alarm.
Setup safety interlock device between systems
- 20 years experienced engineers, customized service avaliable.
- After-sale service support will be provided within 24hours.
Technical Parameter
| Item | QH698 | QH6912 | QH6915 | Q6920 | Q6925 | Q6930 | Q6940 |
| Effective cleaning width (mm) | 800 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
| Dimension of inlet opening(mm) | 800*1600 | 1200*2000 | 1500*2500 | 2000*400 | 2500*800 | 3000*800 | 4000*400 |
| Length of cleaning pieces (mm) | 1200-12000 | 1200-6000 | 1200-12000 | 1200-12000 | 3000-12000 | 2400-12000 | 4500-18000 |
| Roller speed(m/min) | 0.5-4 | 0.5-4 | 0.5-5 | 0.5-4 | 0.5-4.5 | 0.5-4 | 2-8 |
| Abrasive flow rate(kg/min) | 8*120 | 4*250 | 4*250 | 6*250 | 6*250 | 6*360 | 8*360 |
| Abrasive initial filling (kg) | 4000 | 4000 | 4000 | 4500 | 4500 | 8000 | 11000 |
| Roll brush adjustable height(mm) | 4000 | 200 | 350 | 450 | 600 | 850 | 900 |
| Ventilation capacity(m3) | 22000 | 17560 | 19000 | 19550 | 27758 | 28050 | 38000 |
| Outline dimension(mm) |
25017*4500 *9015 |
12180*4250 *7095 |
15200*5370 *6797 |
30650*6850 *9095 |
31200*8070 *7500 |
44042*6385 *7758 |
45000*7830 *11117 |
| Thickness of cleaning steel plate(mm) | 3-60 | 3-60 | 1.5-60 | 3-60 | 3-60 | 3-110 | 4.5-100 |
| Pit depty(mm) | 1937 | 1616 | 2257 | 2800 | 2353 | 2800 | 4317 |
| Power(dedusting excluded) mm | 90 | 78.3 | 113.5 | 156.6 | 224.55 | 204.8 | 293.6 |
| Weight(T) | 20 | 20.4 | 33 | 41 | 53.2 | 71.8 | 75 |
Photos
Please feel free to contact us for more information.
Following details will help us provide better advice for your consideration.
- What kind of workpiece will you clean? (name, material, processing craft)
- The size of workpieces(max. & min. L*W*H)
- Weight of pieces (max. & min.)
- Main purpose (for sand remove or descaling or other?)
- Requirement for efficiency?
Shot blasting machines:
Client visiting
Packaging & Shipping
Our Services
- 20 years experienced engineers provide best proposal for your need.
- Customized design available
- Oversea engineer service avaliable
- To aim to save your cost and improve efficiency
Company Information
Processing workshop:
Dongheng also manufacture variety of foundry machinerys, such as shot blasting machine, moulding machine, core shooting machine, resin and clay regenrate machine, stone shot blast machine etc.
Any interest, please contact us.
