Specifications
Explosion protection Blast furnace Blower:1.Blast furnace blower
2.Explosion protection
3.Long life
4. ISO 9001
Explosion protection Blast furnace Blower
Hengtong Blower products in each big industry were used as key equipment, among dust removal blower, boiler blower, Material Ventilation blower , cooling blower, high temperature blower , Blast furnace Blower etc were used in industrial and civil fields.
Dust collector |
Hengtong blower is a leading provider of fans and blowers for dust collection applications, our fans are used to supply dirty corrosive air into the system, and exhausting clean air out of the system. whether it is sawdust, metal scraps, or welding smoke, Blast furnace Blower .we design and manufacture various pre-engineered and custom heavy duty fans to capture the particles exhausted into the air. |
power generation |
Hengtong blower provide all kinds of air handing products to meet the requirements of power generation industry. We provide fans and blowers that supply, exhaust contain and cool airflow within various applications. From industrial boilers systems and specialty cooling applications to dust collection systems, our pre-engineered and custom heavy duty fans are designed by engineers with power generation applications in mind. |
Boiler system |
According to different applications, boiler system are used for generating steam and electric energy in many different industries, boiler system needs forced draft fans to offer combustion air , Blast furnace Blower .at the same time, induced draft fan remove products of combustion and maintain the required draft. over-fire air fan, primary air and FGR fan are used to circulate gases to different parts of the system. Hengtong blower is a leading provider of pre-engineering and heavy custom duty fans for boiler system. |
The Explosion protection Blast furnace Blower :
Impeller :Impeller annealed completely eliminate welding stress generated when the structure to ensure that the shape of the impeller does not occur creep and cracks.
Motor:General motor, high voltage, frequency conversion motor or custom is appropriate for your system.
Overall support:Overall support is your installation is very simple and easy operation
Casing: Rugged enclosure design, selection of appropriate electrode for welding high-strength , ensure that housing more durable.
Belt pulley: The structure is compact save a space ,differential transmission.
| Application | Temperature | Normal temperature Air | |||
| Hot Air | |||||
| Air composition | Clean air | ||||
| Dusty air | |||||
| Corrosive gas | |||||
| Combustible gas | |||||
| Powder materials | |||||
| Light particle materials | |||||
| Performance | Impeller diameter | 400 | ~ | 3200 | mm |
| Speed of mainshaft | 730 | ~ | 2550 | rpm | |
| Pressure range | 402 | ~ | 5358 | Pa | |
| 3.015 | ~ | 40.185 | mmHg | ||
| 41.02040816 | ~ | 546.7346939 | mmH2O | ||
| Flow range | 5508 | ~ | 119491 | m3/h | |
| 9362.570117 | ~ | 2013112.3576 | CFM | ||
|
System configuration |
Motor | SIEMENS, ABB, LA… | Can assign | ||
| Impeller | Carbon steel | ||||
| Impeller cone (Air Inlet) | Carbon steel | ||||
| Case | Carbon steel | ||||
| Air damper | Carbon steel | ||||
| Main shaft | High-strength carbon structural steel | ||||
| Bearing | FAG, SKF, ZWZ, C&U… | ||||
| Bearing housing | Cast iron | ||||
| Drivetrain | Coupling | Can assign | |||
| Foundation bolt | Carbon steel | ||||
If you are interested in our Explosion protection Blast furnace Blower , Please don't hesitate to contact me !
