Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > Industrial Lathe Machine/Bench Lathe/Horizontal Lathe/Engine Lathe

Industrial Lathe Machine/Bench Lathe/Horizontal Lathe/Engine Lathe

Industrial Lathe Machine/Bench Lathe/Horizontal Lathe/Engine Lathe thumbnail-1
Industrial Lathe Machine/Bench Lathe/Horizontal Lathe/Engine Lathe photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Contact Supplier Request Quote Chat Now
Shanghai THL Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Horizontal
CNC or Not Normal
Place of Origin China
Brand Name THL
Model Number CW6263C

Specifications

Industrial Lathe Machine
1.Bed width 550mm .
2.Spindle bore 105mm,130mm

Industrial Lathe Machine
1.Bed width 550mm .
2.Spindle bore 105mm,130mm

Industrial Lathe Machine/Bench lathe/Horizontal lathe/Engine lathe

Model

Units

CW6263C

CW6273C

CW6283C

CW6293C

Swing Over bed

mm

630

730

830

930

Swing in gap

mm

800

900

1000

1100

Swing over cross slide

mm

350

450

550

650

Distance between centers

mm

750,1000,1500,2000,3000,4500,6000

Length in gap from face plate

mm

300

Spindle nose



C11 or D11

Spindle bore

mm

105,130

Spindle speeds

rpm/steps

10-800/18

Cross slide travel

mm

480

Top rest travel

mm

225

Rapid traverse

mm/min

Axe Z:3200,X:1900

Quill diameter

mm

90

Quill travel

mm

260

Quill taper



MT5

Bed width

mm

550

Metric threads

mm/kinds

1-240/53

Inch threads

tpi/kinds

30-2/31

Module threads

mm/kinds

0.25-60/46

Diametral pitch threads

lpi/kinds

60-0.5/47

Main motor power

kw

11

Packing size

Length

mm

3460,3390,3795,4330,5310,6810,8310

Width

mm

1400

Heigth

mm

2000

Gross weight

kg

4250

4450

4650

4900

4500

4700

5100

5300

5000

5200

5600

5800

5500

5700

6100

6300

6200

6200

6600

6900

7300

7300

7600

7900

8300

8500

8600

8700
