Power Fittings / Power Accessory / Power Hardware

US$ 1 - 50 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

TCI

Model Number:

XGU series

Dalian Tucheng International Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

dalian shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name TCI

Model Number XGU series

Type Other, suspension Clamp,XGU

Material Other, malleable iron

Application High Voltage

Rated Voltage 25kv-180kv

Tensile Strength 3000lbs

Specifications

Power Fittings / Power Accessory / Power Hardware
TCI suspension clamp (aluminium-alloy envelope type)
1.china direct supplie

Product Description

TCI suspension clamp (aluminium-alloy envelope type)
1.china direct supplier
2.delivery on time
nnection of conductors

Suspension clamp is used for the connection of conductors, ground wires to insulator stringgs or hanging to the tower .

Suspension Clamp
Suspension Clamp
Type	suitable Conductor (with wraps)(mm)	Dimensions(mm)				Uitimeate strength(kN)	Weight (kg)
Type	suitable Conductor (with wraps)(mm)	L	H	R	C	Uitimeate strength(kN)	Weight (kg)
CGH-3	12.4-17.0	200	65	9.5	22	40	1.5
CGH-4	19.0-21.6	220	70	12	28	40	2.2
CGH-5	24.2-28.0	250	75	15	35	40	2.8

Suspension Clamps
Suspension Clamps
Type	suitable Conductor (with wraps)(mm)	Dimensions(mm)			Uitimeate strength(kN)	Weight (kg)
Type	suitable Conductor (with wraps)(mm)	L	H	R	Uitimeate strength(kN)	Weight (kg)
XGU-5B	23.0-33.0	300	137	17	60	5.4
XGU-6B	34.0-45.0	300	143	23	60	5.8
XGU-7B	45.0-48.7	300	146	26	60	5.4
