Specifications
1-IEC/ANSI Standard2-5000Hours Aging Test and Type Test
3-ISO Certificate
4-Best Price and Quality of Composite Insulator
10kv composite suspension insulator type disc insulator
1.Size and technical data of 10KV Suspension Composite Insulator
TYPE:FXBQW4-10/70
| Rated voltage(KV) | Rated mechanical tension load(KN) | Structure of coupling marks | Structure height(mm) | Min.Electric arc distance(mm) | Min nominal creepage distance(mm) | Full wave lightning impulse withstand voltage(peak value)not less than(kv) | 1min power frequency wet withstand voltage not less than(kv) |
| 10 | 70 | 16 | 370±15 | 170 | 400 | 115 | 45 |
2.Materials of 10KV Suspension Composite Insulator
1).Silicon Rubber for sheds/housing
2).Glass-fiber reinforced epoxy resin rod(ECR type)for core
3).Hop dip galvanized cast steel for metal fittings
4).5000hours aging test.
5).IEC standard.
Tips: Since we (TCI) have many different models and types,providing exact model or detailed technical specification in your inquiry will largely help us finding your a better solution within less time and reducing your communication cost.
Contact with me:Jeff Song 24Hours in
Email me:song@tcipower.com
Dalian Tucheng International Corp.
Dalian Composite Insulator Corp.
Fax: +86 411-82789913
