GTJZ0812 Self-propelled hydraulic scissor lifts are mostly applied to flat indoor or outdoor. The body is pleasing to eye and flexible to operate. The main engine can travel and turn automatically. It features imported hydraulic components, explosion-proof pipe unit and emergency descending switch; hydraulically driven ascending, descending and travelling function; low in noises and free of air pollution; durable, chip-free, skid-proof and traceless tires without scratching the ground; optimized product control mode and procedure with the premise of safety, bringing much more humanized operation.
Technical parameters
Models |
GTJZ0812 |
|
Dimensions | ||
Platform height max. |
26.6 ft (8.1 m) |
|
Working height max. |
33 ft (10.1 m) |
|
Platform extended |
3 ft (0.9 m) |
|
Length - stowed |
7.84 ft (2.39 m) |
|
Width - stowed |
3.77 ft (1.15 m) |
|
Height - guardrail folded |
6.43 ft (1.96 m) |
|
Height - guardrail unfolded |
7.7 ft (2.35 m) |
|
Height - guardrail fixed |
7.7 ft (2.35 m) |
|
Wheelbase |
6 ft (1.85 m) |
|
Ground clearance |
0.33 ft (0.1 m) |
|
Platform size (L*W*H) |
7.4 ft * 3.77 ft * 3.6 ft (2.25 m*1.15 m*1.1 m) |
|
Productivity | ||
Max. platform occupancy |
2 (indoor), 2(outdoor) |
|
Lift capacity |
992 lbs (450kg) |
|
Driving speed - stowed |
0~3.2 km/h |
|
Driving speed - raised |
0~0.8 km/h |
|
Gradeability |
25% |
|
Turning radius - inside |
0 ft (0 m) |
|
Turning radius - outside |
7.7 ft (2.35 m) |
|
Raising / Falling speed |
30s~35s /35s~40s |
|
Controls |
Proportional |
|
Drive &steer model |
2WD, front -wheel |
|
Brake |
2 rear-wheel |
|
Tire |
380 mm * 125 mm/solid |
|
Power | ||
Power source |
24V DC (4*6V, 225Ah batteries) |
|
Hydraulic system tank vol. |
18 L |
|
Power |
3 KW |
|
Weight | ||
overall weight ( indoor/outdoor ) |
5490 lbs (2490 kg) |
|
Standards Compliance |
CE/ ISO/ ADR/ ARAMCO |
|
The core configuration
Production Line
Product Inventory
Application
Worldwide Show
About Us
Sinoboom is engaged in research, development, manufacturing, sale and service of aerial work equipment. There are four series of aerial work platforms, including articulated boom lift, telescopic boom lift, scissor lift and spider lift, with working height from 4M - 42M in full series and various types, we owns the proprietary core technology and 30 items of intellectual property.
