Remote Wireless Industrial Ultrasonic Water Flowmeter/Heat Meter
Principle
-Industrial Ultrasonic Water Flowmeter/Heat Meter measurement principle: Ultrasonic transit-time method.
An industrial ultrasonic water flowmeter plus counterpart temperature sensor make professional ultrasonic cold heat meters.
-Dual-channel and multi-channel working principle: Mono / dual channel / multi-channel available for size greater than DN100.
A ultrasonic water flowmeter usually uses mono channel to measure, for applications requiring high precision, can use multi-channel. Multi-channel ultrasonic water flowmeter give the channels a level layout, it measures the fluid cross-sectional velocity distribution function, working with the introduction of the concept of calculus,using function difference method to realize multi-channel measurement, it minimizes the measurement error by calculation of double integral corresponding to the cross-sectional area distribution and velocity distribution.
Specifications
-Measurement Principle: ultrasonic transit-time method
-Measurement period: adjustable
-Measurement show: auto cycle/magnets/manual keys optional
-Water flow meter precision: level 1 or 2
-Heat meter precision: level 2 or 3
-Temp sensor: PT1000/PT100
-Connection: Flanged or threaded
-Environmental rating: A
-Battery life: 6 or 12 years optional
-Working pressure: 0.6-2.5MP
-Pressure test: ≤0.6-2.5MP
-Pressure loss: 0.025MP(commonly used flow)
-Ambient temperature: -30 C°-80 C°
-Temp test range: -40-162 C°
-Temp difference allowed: 3-70C°
-Temp difference resolution: 0.01C°
-Thermal energy range: hot and cold dual
-Quiescent Current: 10 Ua
-Platinum resistance wire length: optional
-Installation location: into/back water dual -use
-Protection degree: IP65/IP68/IP54 optional
-Working power: 3.6V Lithium-Ion battery, 220V AC/24V DC optional
-Installation: Integrated and split optional
-Flow sensor installation: Standard flange / threaded connection / plug-in optional
-Tube diameter application: DN15-DN600, can customize to DN1200
-Data storage: more than 10 years
-Power consumption: Diameter 100 mm, measurement period 1 second 1.05 mw,3 second 0.35 mw,auto power saving mode in case of empty tube, reduces power consumption by 30%
-Output mode and the communication protocol: M-BUS, RS 485,pulse,GPRS interface optional, support M-BUS and RS485 BUS mode,international communication protocol
-Channel: mono/dual/multi channel optional for diameter ≥DN 100. The sensor is specially treated and the
Features
-Maintenance-free design for 10 years
-Encapsulated cell continuous working for 6 or 10 years, (user can also use external power supply 24V DC or 220V AC)
-Low starting flow as low as 0.002 m/s
For more information,please contact us freely without any hesitation,Thank you.
