Mini Small Table UV Conveyer Dryer curing Machine TM-200UVF

Specifications

uv curing machine
1.small Volume and easy carrying
2.drying printing UV ink ,UV paper printing ,UV glue

Mini Small Table UV Conveyer Dryer curing Machine TM-200UVF



Our last new Desktop style  UV Curing Model is TM-200UVF. it is small Volume and easy carrying .widely  use for  of field of drying  printing UV ink ,UV paper printing ,UV glue ,UV tunnel drying ,UV PRINTEER,UV Packing , UV testing .favorable price and high quality .



1.Manipulation of the equipement is simple.

2.The product is developed as low output/low price.

3.Can select from separation type and conveyor type.

4.There is little space limitation since the size ia small.

Tech  Parameter
1.  Model  NO. TM-200UVF
2.  max product width: 200mm
3.   max product length:800mm
4.  UV Process shine area:200×800mm
5.  conveyer speed: 0-12m/min
6.UV Lamp power:2KW *1 PCS/
7. conveyer belt size:800*200 (L*W)
8. UV light power supply: 220V/50 HZ

9.UV Machine  Dimension: 810×430×850mm(L×W×H)
11.Net Weight:110kg

Small Table--style UV Curing Machine



Model number	TM-200UVF	TM-300UVF	TM-400UVF
style	Desktop	Desktop	Desktop
max product width	200mm	300mm	400mm
max product length	1000mm	1200mm	1200mm
UV Process shine area	200×1000mm	300×1200mm	400×1200mm
conveyer speed:	0-10m/min	0-10m/min	0-10m/min
UV Lamp power	2KW ×1 PCS/	2KW ×2 PCS/	2KW ×2 PCS/
conveyer belt size	200×1000mm	300×1200mm	400×1200mm
UV Machine  Dimension:	1100×220×750mm	1300×320×750mm	1300×420×750mm
Net Weight	110kg	130kg	165kg

Free Fitting :
one pcs UV lsmp  (2000W)

Price Terms --FOB or CFR
Payment Terms--- T/T or LC
Packing ----wooden crate
Lead Time ----5days after confirm Payment
SKU ----10 SETS
Standards Certificate ---CE
Cubic Meter---- 0.85
Gross Weight ---65KG
