Two uv Curing Independent System UV Drying Machine TM-500UVF

Two uv Curing Independent System UV Drying Machine TM-500UVF photo-1
Two uv Curing Independent System UV Drying Machine TM-500UVF photo-2
US$ 2,500 - 3,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Drum Drying Equipment
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Drum Drying Equipment
Place of Origin Guangdong, China
Brand Name LC
Model Number 500UVF
Voltage 380V
Power(W) 3KW/1PCS
Dimension(L*W*H) 2020*550*1200mm
Weight 250KG
Certification CE
Warranty 1 Years
After-sales Service Provided Engineers available to service machinery overseas

Product Description

Product name

UV Drying Machine

Model No

LC-TM-500UVF

Certificate

CE, ISO-9001-2000

Brand Name

LC,China

Parameter

1.Model  NO. TM-500UVF
2.UV Drying products:500*100*2000mm
3.Conveyor belt size:L2000* W500MM
4.UV Lamp power:2PCS*3KW /380V
5.Total wattage:7.5KW

6.Wind fan wattage: 500W/380V

7.motor wattage:1000W/1P/380V

8.Conveyor speed:0~10m/min

9.Speed change ways:Continue

10.UV Machine  Dimension:L*W*H2020*700*1350

11.Weight:250kg

Free fittings

1. 1 bag tooling box
2. 1 pcs English operating instruction

Advantage

1. The conveyer speed can adjustment according to the products drying condition;
2. Conveyer belt mabe by tefulong materials;
3. Famous brand UV lamp installed ;
4. Cooling fan installed on the side to remove the heat in curing chamber;

Description

Plane UV curing machine is used for curing printed UV ink,UV glue,UV paint,UV varnish etc.
UV Lamp lifetime can reach 1000-1200 hour. Lowest and highest UV lamp operating temperature

 is 50 degrees Celsius and 75 degrees Celsius respectively. Driven by well-known motor, stepless speed adjustment.The Conveyor speed can be adjusted according to product’s

characteristics

Usage

Electron, Hardware, Auto, Toys, Gifts, Plastics parts,Plastics products, House appliances, work of art,

Stationery, Ornament, cosmetic, sports apparatus .UV drying for UV ink .

customer

USA, Germany,Europe,South Africa, South Asia,South-east Asia etc

Delivery time

Within 7 days from the receipt of payment

Loading seaport

Shenzhen or Hong Kong, China

package

Plywood case/ as required

Price term

FOB Shenzhen, CFR, CIF, FCA, EXW etc

Machine pics



Two uv curing independent system UV Drying Machine TM-500UVFTwo uv curing independent system UV Drying Machine TM-500UVFTwo uv curing independent system UV Drying Machine TM-500UVFTwo uv curing independent system UV Drying Machine TM-500UVF

Why choose us?







Company Information
1.We have exported to more than 85 countries! including USA, Mexico,France,Spain,India,South Africa etc
Two uv curing independent system UV Drying Machine TM-500UVF2.We are professional manufacturer of pad, screen printer, hot stamping machine, UV curing machine etc for 22 years!

Two uv curing independent system UV Drying Machine TM-500UVF







Our Services
3.We have most reliable aftersales service group and technical engineer team, the all process include design, production,testing,package,delivery is controled strictly!Two uv curing independent system UV Drying Machine TM-500UVF







FAQ

4.We are located in China industrial zone center ---Dong-guan It's only two hour's car ride far from Guangzhou airport. If you are interested in our products, Welcome  Agented

Two uv curing independent system UV Drying Machine TM-500UVF





Packaging & Shipping

Two uv curing independent system UV Drying Machine TM-500UVFTwo uv curing independent system UV Drying Machine TM-500UVF
