TC-200R Hot Foil Stamping Machine

TC-200R Hot Foil Stamping Machine thumbnail-1
TC-200R Hot Foil Stamping Machine thumbnail-2
TC-200R Hot Foil Stamping Machine photo-1
TC-200R Hot Foil Stamping Machine photo-2
US$ 4,900 - 5,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Gravure
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Luen Cheong Printing Equipment Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Yantian ShenZhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Gravure
Place of Origin Guangdong, China
Brand Name LC
Model Number TC-200R
Usage Card Printer, Paper Printer
Automatic Grade Semi-Automatic
Voltage 220V
Gross Power 50W
Dimensions(L*W*H) 1260*600*1850mm
Weight 420KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.CE certificate and High quality
2.Good pricing and be equiped with laser electric eye sensor



Product Description







TC-200R Hot foil pritning machine .
1.Model Number:TC-200R ,TC-200R heat transfer machine.
Machine stability. 8mm thickness of the cast iron body and a shape. Durability, service life of up to 30 years.

2.Be equiped with laser electric eye sensor
3.Heat transfer size--200mm Length:150mm
4.Dia. of the transfer roller --100mm Length:150mm
5.Power -1500W
Taiwan pressure cylinder with a diameter of 120mm.
Excellent stamping thermal transfer. Thermostat, stamping pressure is stable.
Blanching printed circular object. Diameter of 140mm. Length of 150mm.
The thermal transfer Cots: outer diameter 100mm. Length 150mm.
With the laser electric eye sensor.
 Power consumption: 1500W



Features:
1, the toggle mechanism design, strong pressure, air pressure consumption;
2, stamping pressure, temperature, transfer time is adjustable;

3, the table can be moved manually before and after, to facilitate the safe and quick operation;

4, the table can be around the rotation adjustment

5, automatic document feeder, the collection of paper, and can adjust;

6, stamping head lift height adjustable;

7 shuttle table driven the the workpiece smooth rotation Stamping stamping quality is stable.

8 for stamping curved or round face, remove the shuttle table is the plane tipping machine.

Technical parameters:

The Max.Stamping pressure ≤ 1000kgs

Max stamping diameter / full circle printing Φ140mm/Φ60mm

Stamping head height adjustable stroke: 53mm

Thermal transfer Cots area: outside diameter: 100 × length of 150mm. Red 45 degrees -85 degrees customersfreedom of choice.

Stamping temperature the selection room temperature: 280 degrees

Heating power 1500W

6.Machine Dimensions(L*W*H)- L1260*W600*H1850mm
7. Air pressure: 5-7Ba
TC-200R heat transfer machine.
Machine stability. 8mm thickness of the cast iron body and a shape. Durability, service life of up to 30 years.
Taiwan pressure cylinder with a diameter of 120mm.
Excellent stamping thermal transfer. Thermostat, stamping pressure is stable.
Blanching printed circular object. Diameter of 140mm. Length of 150mm.
The thermal transfer Cots: outer diameter 100mm. Length 150mm.
With the laser electric eye sensor.
 Power consumption: 1500W








Price Terms FOB CHINA
Packing Plywood case
Lead Time 5 days
Standards Certificate ce
Volum 2.2
Application area learth , toys , plastic parts
Gross Weight 420kg
Main Parts FESTO CYLINDER & HEATING
Free Fittings GOLD FOIL 120m*5mm
de 8443391200





TC-200R hot foil stamping machine





TC-200R hot foil stamping machine



TC-200R hot foil stamping machine
