Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E

Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E thumbnail-1
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E thumbnail-2
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E thumbnail-3
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E thumbnail-4
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E thumbnail-5
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E photo-1
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E photo-2
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E photo-3
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E photo-4
Large Container Screen Printer Cylindrical Screen Printing Machine LC-1200E photo-5
US$ 5,400 - 5,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
LC
Contact Supplier Request Quote Chat Now
Luen Cheong Printing Equipment Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Guangdong, China
Brand Name LC
Model Number LC-1200E
Usage Other, Screen Printer
Automatic Grade Automatic
Voltage 220V
Gross Power 50W
Dimensions(L*W*H) 1720*1600*1650 mm
Weight 230KG
Certification CE
Warranty 1 YEAR
After-sales Service Provided Engineers available to service machinery overseas
 Cylinder screen printers are multifunctional screen printing machine. They are suitable to print on flat, round, oval shaped products.
Cylinder screen printers can print one color at one time. Once replacing frame and ink, they can print 2, 3^colors.


1. Model number: LC-1200E
2. Product appearance: Round /oblate
3. (Round)Max. Printing diameter: Φ375mm
4. (Round)Max printing arc length: L: 1170mm
6. Printing Speed: 800 PC/H
8. Machine/ Weight: 230kg
6. Air pressure: 0.5Mpa
7. Voltage power: 220V/ 60HZ or 110V/50HZ
Model number LC-PA-300E LC-PA-400E LC-600E LC-700E LC-1200E
(Round)Max Printing diameter 82 mm 120mm 180mm 220mm 375mm
(Round)Max printing area 300×260mm 300×360 mm 300×570mm 350×670mm 420×1170mm
(oblate)Max printing diameter: 420mm 500mm / / /
(flat) Max printing area 260*220mm 320*; 220mm / / /
Max Workpiece rake <14° <14° <14° <14° <14°
Air pressure 6bar 6bar 6bar 6bar 6bar
power 50W 50W 50W 50W 50W
Voltage AC110V/220V AC110V/220V AC110V/220V AC110V/220V AC110V/220V
Printing speed 1300P/H 1200P/H 1100P/H 900P/H 800PH
Machine appearance(mm) 850×850×1280 1080×850×1280 1200×1100×1450 1200×1180×1450 1720×1600×1650
Machine weight 120kg 145kg 200kg 210kg 230kg
cylindrical screen printing machine :
1. Microprocessor controls, high automation and easy operation.
2.4-digit auto counter built-in.
3. With the function of cylindrical and conical printing.
4. Automatic ink scraping, ink withdrawing and worktable lifting.
5. Printing stroke and speed is adjustable to meet different needs.
6. Automatic squeegee balance-keeping ensures equal printing pressure.
7. Worktable and screen frame can be adjusted slightly in horizontal and vertical direction.
8. High precision printing and easy adjustment.



Testing Please provide:
1.110V or 220V power supply.
2.5-7 bar compress air.
3. Esposal screen plate 1 pcs.
4. A jig 1pcs.
5.5-10 pcs product samples.

Price Terms-- FOB or CFR
Payment Terms ---T/T or L/C
Packing Wooden --case
Lead Time ---5 days after confirm Payment.
SKU ---10 set
Standards Certificate-- CE
Cubic Meter ---1.8
Machines Fittings Screen Cliche
Gross Weight ----230KG
Main Parts FESTO cylinde made by Geramny
Application area detergent bottles, Pens, beverage bottles, cups, cans, , Cosmetics package box, lipstick tube,







Price Terms FOB CHINA
Packing PLYWOOD CASE
Lead Time 7 DAYS AFTER PAYMENT
Standards Certificate CE





Large Container Screen Printer cylindrical screen printing machine LC-1200ELarge Container Screen Printer cylindrical screen printing machine LC-1200ELarge Container Screen Printer cylindrical screen printing machine LC-1200ELarge Container Screen Printer cylindrical screen printing machine LC-1200E
