Automatic Single Cylinder uv Printer Lc-120uv-1

Luen Cheong Printing Equipment Ltd.
Automatic Single Cylinder uv Printer Lc-120uv-1 thumbnail-1
Automatic Single Cylinder uv Printer Lc-120uv-1 photo-1
US$ 20,579 - 21,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
LC
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Guangdong, China
Brand Name LC
Model Number LCB-120UV-1
Usage Label Printer, Tube Printer
Automatic Grade Automatic
Voltage 380V
Gross Power 50W
Dimensions(L*W*H) 1900*1000*1500 mm
Weight 1050KG
Certification CE
Warranty 1 YEAR
After-sales Service Provided Engineers available to service machinery overseas

Specifications

High quality and good pricing and service
automatic screen printing machine
uv printer


Product Description



Automatic Single Cylinder uv printer lc-120uv-1

Full  Automatic One Colour Cylinder Screen Printer LCB-120UV-1.
This auto printing press system is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc



1. MAIN MOTOR: SITI(Italy)
2. PLC: Omron(Japan)
3. SENSOR: Optex(Japan)
4.TOUCH SCREEN: Proface(Japan)
5. Switch: Schneider(France)
6. (CONTACTOR): (Schneider)(France)
7(RELAY): (Idec)(Japan)
8. (INVERTER): Omron(Japan)
9. (UV CURING)(Primarc brand uv lamp ) Britain
10. (PNEUMATIC): Festo(Germany)


1 Model No:LCB-120UV-1
2.Printing colors:1 color
3.Product appearance:Round bottle /  oblate bottle
4.Operation:Full Auto
5.min printing diameter:round bottle: 20 mm
6.max printing diameter:round bottle :100 mm
7.min printing radius:oblate bottle :25 mm
8.max printing radius:oblate bottle :260 mm
9.oblate bottle width:20-100 mm
10.oblate bottle thickness:20-80 mm
11.Max Printing speed:4000-5000Pcs/Hr
12.Power:380V
13.Weight:1050(kg)
14.Dimensions:L:1900×W:1000×H:1500(mm)

1-COLOUR AUTO SCREEN PRINTER
Model NoLCB-120UV-1LCB-150UV-1LCB-350UV-1
Printing colors1 color1 color1 color
Product appearanceRound bottle  oblate bottleRound bottle  oblate bottleRound  bottle
OperationFull AutoFull AutoFull Auto
min printing diameter(round bottle)20 mm20 mm150 mm
Max printing diameter(round bottle)100 mm150 mm350 mm
min printing radius (oblate bottle)25mm25mm/
max printing radius (oblate bottle)260mm300mm/
oblate bottle width20-80 mm20-100 mm/
Max Printing speed4000-5000Pcs/Hr4000-5000Pcs/Hr2000Pcs/Hr
Power380V380V380V
Weight1050kg1360kg1550kg



1.Full automatically printing suitable to print on various shades of cylindrical, elliptical and falt workpieces;

2.Coupled with auto workpiece feeding and loading system;

3.Flame treatment device adopted for re-treatment on PE or PP workpieces to get ultimate ink adhesion;
4.The function of workpiece placing in advance is built-in aiming on cylindrical or elliptical printing;
5.Electric sensor creates "no workpiece no printing" that leads to intelllgent monitor and smart control;
6.High quality UV curing system adopted to ensure fast ink drying and color registration;
7.High printing speed that up to 4000pcs/hr will bring you with high productivity;
8.Conveniently and easily fixture adjustment and change that save your valuable time;
9.Multi-sets of this machine can achieve 2-color, 3-color and even 4-color auto printing system.








Price TermsFOB SHENZHEN PORT CHINA
Packingwooden case
Lead Time25 days after deposit
Standards CertificateCE
Volum4.8
Application areapackage of cosmetic, lipstick, bottles.
Gross Weight1300KG
Main Parts1. MAIN MOTOR: SITI(Italy) ,3. SENSOR: Optex(Japan)
Free Fittings SILK SCREEN PLATE ,SQUEEGEE,





Automatic Single Cylinder uv printer lc-120uv-1Automatic Single Cylinder uv printer lc-120uv-1Automatic Single Cylinder uv printer lc-120uv-1Automatic Single Cylinder uv printer lc-120uv-1









Automatic Single Cylinder uv printer lc-120uv-1





Packaging & Shipping





wood case









Our Services

free mend forever
