Home > Metallurgy, Mineral & Energy > Non-ferrous Metal & Products > Molybdenum > 99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys

Name: 99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys
Brand: Boxin
SKU: 113622387

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys thumbnail-1

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys thumbnail-2

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys thumbnail-3

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys thumbnail-4

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys photo-1

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys photo-2

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys photo-3

99.95% ASTM B386 Molybdenum Plates Heets Foils Strips and Their Alloys photo-4

US$ 50 - 150 MOQ: 2 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Shaanxi, China

Brand Name:

Boxin

Model Number:

Molybdenum 360 361364

Contact Supplier Request Quote Chat Now

Baoji Boxin Metal Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xi'an Tianjing Shanghai by air

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shaanxi, China

Brand Name Boxin

Model Number Molybdenum 360 361364

Dimensions thickness 0.1mm to 30mm

99.95% ASTM B386 Molybdenum plates heets foils strips and their alloys

1.Designation:

Mo1, Mo3G(MoLa10), TZM(molybdenum alloy364), Molybdenum360, Molybdenum361

2.Technical condition:

GB3876-83(Chinese standard for molybdenum plate)

GB3877-83(Chinese standard for molybdenum foil)

ASTM B386-91(American standard for molybdenum plate, sheet, foil and strip

3.Application: electron, aviation, aerospace, electric light, electron- vacuum, heating bodies and heat shields, molybdenum boat and crucibles etc.

Note: high temperature Molybdenum plates, sheets are hot/cold rolled by unique technology, the products gain more high temperature property by increasing the recrystal temperature of molybdenum by 500-700.having met the using temperature 1850 of heat shields materials for vacuum furnace.

4.Designation, condition and size of molybdenum plate:

Table 1

Designation	Method	Condition	size(mm)
Designation	Method	Condition	Thickness	Width	Length
Mo1 Mo3G TZM(Mo364) JMo1 Mo361	Powder metallurgy	(Y) (m)	0.1~1.0	50~600	100~2000
Mo1 Mo3G TZM(Mo364) JMo1 Mo361	Powder metallurgy	(R)	1.0~30	50~600	100~1500
Mo1 Mo360	vacuum electric arc smelting	(Y) (m)	0.1~1.5	50~600	100~2000
Mo1 Mo360	vacuum electric arc smelting	(R)	1.5~30	50~600	100~1500

5.Tolerance of thickness, width and length

Table 2 unit: mm

Thickness	Tolerance of thickness		width	Tolerance of width	length	Tolerance of length
Thickness	Class I	Class II	width	Tolerance of width	length	Tolerance of length
0.10~0.15	±0.01	±0.02	50~200	±2.0	100~2000	±5.0
>0.15~0.30	±0.02	±0.03	50~500	±2.0	100~2000	±5.0
>0.30~0.50	±0.03	±0.04	50~600	±2.0	100~2000	±5.0
>0.50~0.70	±0.04	±0.05	50~600	±3.0	100~2000	±5.0
>0.70~1.0	±0.05	±0.08	50~600	±3.0	100~2000	±5.0
>1.0~2.0	±0.06	±0.10	50~400	±5.0	100~1200	±5.0
>2.0~3.0	±0.08	±0.15	50~400	±5.0	100~1200	±5.0
>3.0~4.0	±0.10	±0.20	50~400	±5.0	100~1200	±5.0
>4.0~5.0	±0.12	±0.30	50~400	±5.0	100~1200	±5.0
>5.0~30.0	±0.20	±0.50	50~400	±5.0	100~1200	±5.0

Company

other products:

Do you have any very special requirements? For us, that's not a problem: As a specialist in the field of refractory metals, we can adapt the tensile strength and surface properties of our sheets to meet your specific needs.

Just contact us!
