Help CenterRealand Rfid Card and Fingerprint Access Control System Door Access Control System M-F131
Related Products
-
Danmini Hot Selling Realand Fingerprint / RFID Card Door Access Control M-F211US$ 45 - 50MOQ: 10 Pieces -
Hot Selling Realand Fingerprint Card Time Attendance Access Control MF210US$ 30 - 83.33MOQ: 10 Pieces
-
Realand Fingerprint Card Access Control and Attendance MF210US$ 30 - 83.33MOQ: 10 Pieces
-
Realand Fingerprint / RFID Card Door Access Control M-F211US$ 45 - 50MOQ: 10 Pieces
-
Rfid Card and Fingerprint Access Control System Door Access Control System M-F131US$ 60 - 70MOQ: 10 Sets
1.2.4inch TFT Color Screen
2.Fingerprint/Password/RS485/USB memory disk
3.Fingerprint capacity:2000
4.Records capacity:100,000
munication:TCP/IP/RS485/USB
6.Power:DC 12V/1A
7.Open doorby multilevel verfication,anti-pass back 8.Terminal size:181*91*36mm
M-F131 is a robust and professional high-end access control device which have RFID card & fingerprint authentication and with time attendance function. It’s with the leading-edge fingerprint arithmetic in the world, automatically analyze the tiny difference of the latest fingerprints vs. the precious fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition. High recognition ability for injured and peeled fingers, the identification time is less than 1 second. With multi-level validation, lock combination and anti-pass back ect advanced validating functions. The device includes two set locks for output, two set door release buttons, one set Wiegand 26/34 output and input. It could download and upload data & record by U disk flash, TCP/IP communication function, you could realize access control networking and data collection & sharing freely.
2.Features:
1.It’s with the leading-edge fingerprint arithmetic in the world, automatically analyze the tiny difference of the latest fingerprints vs. the precious fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition.
2.The device is built-in ID card sensor (optional for IC card), validate freely by Card, fingerprint and password combination, access control is more flexible and securely.
Support U disk to download or upload attendance records and fingerprint data ect. User could enroll the fingerprint in one device, and share the enrollment information with other devices through the USB flash memory stick.
3.TCP/IP communication, network connection is simple and convenient, support Push Technology, operate access control networking and data collection & share freely
4.With multi-level validation, lock combination and anti-pass back functions.
5.With tamper alarm, over-time door opening alarm, fire alarm and Hijack alarm ect alarm functions
6.Authentication modes are 1:1 and 1:N, user can register ten fingers, max fingerprint capacity is 2,000 enrollment and 100,000 record
7.With two set locks for output, two set door release buttons, those could connect wire or wireless switch.
8.With two groups of Wiegand, one group Wiegand 26/34 for output and one group Wiegand 26/34 for input.
9.Support multi development language(VB, C++, Delphi ect) SDK, and ODM/OEM software development
10.Support English, French, Spanish, Korean ect different languages.
3.Specification:
display |
2.4 inch TFT color screen (320 * 240) |
|
Fingerprint readers |
Optical fingerprint readers (500 dpi resolution:) |
|
CPU |
ARM926EJ core, running frequency 0 ~ 200 MHZ |
|
Identify the point of view |
All angles to identify |
|
Rejected boomed (FRR) |
≤0.1% |
|
Recognize false rate (FAR) |
≤0.00001% |
|
Fingerprint identification model |
1:1,1:N |
|
authentication |
Fingerprint, induction card, password arbitrary combinations |
|
Fingerprint storage capacity |
2000 |
|
Record capacity |
Article 100000. |
|
Induction card |
125Khz, EM4100 |
|
Communication methods |
RS485 / TCP/IP |
|
U disk data upload/download |
support |
|
Language shows |
(Jane, numerous), UK. Other (customizable) |
|
Name displayed |
||
Voice prompt |
Have other language (Chinese pronunciation) can be customized |
|
An alarm function |
Built-in timer rang the bel |
|
Power management function |
Sleep, automatic startup, countdown shutdown, regular shutdown |
|
Senior entrance guard function |
Multistage validation to open the door, the police sneaking into linkage |
|
Alarm function |
Tamper alarm, open the door warning overtime. Duress alarm linkage (fire), forced open the door alarm, alarm input |
|
Lock the output |
The 2 groups |
|
Open button |
The 2 groups (can connect wireless switch, cable switch) |
|
External the doorbell |
support |
|
Wiegand agreement |
Support, Wiegand 26/34 output (group 1) Wiegand 26/34 input (group 1) |
|
Other features |
Offline buffet set period of time, when the group and access permissions. |
|
Working voltage/current |
DC 12V/1A |
|
The work environment |
Temperature: 0 °C ~ + 45 °C, humidity (RH) : 20% ~ 80% |
|
If the total payment is less than 500USD, we usually accept Paypal or Western Union;
For big amount we accept bank transfer, and the sender charge was understook by buyer.
Shipment:
Normally we will use DHL, FEDEX, UPS or EMS express. Shipping usually takes 3-7 working days depending on the country delivered to.
If u want to send by other express, we can accept also.
Warranty:
Warranty for one year, maintenance forever,change within 1 months be cause of product quality.
Technical Support:
If u have any problem for installation using and others, u can Email to me, my company technical and we will try our best to solve it
