PET blowing moulding Machine

Specifications

We can provide performs and cap moulds for 5 gallon and 3 gallon bottle to meet customer's requirements

Specifications

BX-B2 Semi-automatic PET blow molding Machine
1400-2000BPH
0.1-2.0L

1. BX-B2 semi-automatic PET bottle blowing machine is suitable to produce water and soft drink bottles.

2. It is also widely used to produce comestic,medical,pesticide bottles,etc.

3. Feeding system carries the preforms automatically. Infrared lamps adopted in the pre-heater to heat the PET preforms.

4. Semi- automatic process with low investment,high efficiency, quick and safe operation, easy trouble shooting, maintenance and other advantages.

5. This machine can producing PET bottle which can resist high temperature,such like 90 centigrade degree.This has solved the problem of the traditional juice and other liquid food packing.







Technical parameter:

ITEM	UNIT	BX-B2
Cavity	pcs	2
duct capacity	L	0.05
duct capacity	L	2.0
Min.inner neck diameter	mm	15
Max.inner neck diameter	mm	38
duct diameter	mm	120
duct height	mm	320
Max.mould thickness	mm	110-230
Mould opening stroke(Adjustable)	mm	160
Theoretical output	bph	1400-2000
Operating pressure	Mpa	0.8-1.0
Blowing pressure	Mpa	1-3
Max.heating power	kw	14
Machine weight	kg	650*2
Heater weight	kg	230
Machine dimension(L*W*H)	m	1.5×0.7×1.85*2
Heater dimension(L*W*H)	m	1.85×0.7×1.65
