Help CenterSemi-automatic PET Blowing Machine
Related Products
-
Plastic Bottle Blowing MachineUS$ 5,000 - 7,000MOQ: 1 Piece -
5 Gallon Preform,5 Gallon PET Preform,5 Gallon Bottle Preform,5 Gallon Plastic PreformUS$ 1.7 - 1.9MOQ: 1000 Pieces
-
Semi-automatic Bottle Blow Moulding MachineUS$ 6,500 - 8,000MOQ: 1 Piece
-
5 Gallon Blowing Molding MachineUS$ 9,000 - 10,000MOQ: 1 Piece
-
Semi-automatic PET Blow Moulding MachineUS$ 6,500 - 8,000MOQ: 1 Piece
Specifications
We can provide performs and cap moulds for 5 gallon and 3 gallon bottle to meet customer's requirementsSpecifications
semi-automatic PET bottle blowing machine,bottle blowing machine,PET blowing machine.0.1-6L,500-1100BPH.
Features:
BX-C Semi-automatic PET bottle blowing machine can produce PET containers special oil bottle(less than 6 liters) according to the different bottle shapes and diameter.It has semi-automobile system with high efficiency.The far-infrared lamps are used in the machine.It has high pressure protection with the feature of precisely removing mould.The machine has no noise.It is easy to maintain and operate.
Technical parameter:
ITEM |
UNIT |
BX-C |
Cavity |
pcs |
1 |
duct capacity |
L |
0.1 |
duct capacity |
L |
6 |
Min.inner neck diameter |
mm |
45 |
Max.inner neck diameter |
mm |
160 |
duct diameter |
mm |
200 |
duct height |
mm |
350 |
Max.mould thickness |
mm |
170-280 |
Mould opening stroke(Adjustable) |
mm |
230 |
Theoretical output |
bph |
500-1100 |
Operating pressure |
Mpa |
0.7 |
Blowing pressure |
Mpa |
1-3 |
Max.heating power |
kw |
14 |
Machine weight |
kg |
750 |
Heater weight |
kg |
230 |
Machine dimension(L*W*H) |
m |
1.85×0.7×1.9 |
Heater dimension(L*W*H) |
m |
1.85×0.7×1.65 |
