Glass lifting equipment
Customer Glass sheet specification is:
(941)mm L x(1800)mm W x(3-25)mm T, Max. weight less than 400kg.
(1500)mm L x(3000)mm W x(6+6,8+12)mm T, Max. weight less than 400kg.
The equipment specifications as below:
Model Number: GLA400-4-B-M
Max. carrying capacity is 400kg ( a safety factor 4.0 include)
-
Description:
Designed for use with a crane or other hoisting equipment. The GLA400-4-B-M Lifer employs vacuum to hold a load for lifting, and provides Manual rotation, 360° edgewise, with locking at each quarter point and manual tilt, 90° between upright and flat for load manipulation.
Power Supply: Battery-12V, 4A
Capacity: Battery 7Ah
Vacuum pads diameter: 30cm nominal diameter. Lipped (P300FN)
Load capacity: (rated at [-60kPa] on clean, smooth, nonporous flat surfaces)
Per-pad: 423.9kg Safety suction force: 105kg
Maximum(w/4pads):1695.6kg Safety suction force: 423.9kg
-
Load Movement:
Manual rotation, 360° edgewise, with locking at each quarter point
Manual tilt, 90° between upright and flat, with automatic latching in upright position
-
Standard Features:
Low vacuum warning light
On-board battery and charger
Battery energy gauge
Vacuum gauge
Vacuum line filter
Vacuum reserve tank
Spring-mounted vacuum pads
Movable vacuum pad mounts
Vacuum pad extension arms
Manual valve is connected to suction cup separately and the operator can shut off individual suction cup according to the dimension of workpiece. This function is also useful for the self-check of vacuum reservoir.
The vacuum lifter uses USA GAST oilless rotary vanes vacuum pump to be the vacuum generator, the max. Vacuum degree is up to 85%, even no need to fill lubrication and cooling liquid.
The vacuum lifter is equipped with a buzzer and warning light units, in case of a power failure or vacuum leakage, an optical and an acoustic signal goes off immediately to warn the operator to do emergency operation.
The vacuum lifter is equipped with Vacuum reservoir tank helps prevent immediate vacuum loss in case of power failure and extends battery life by reducing pump cycles required to maintain vacuum. when the power is turned off in sudden, always can keep the workpiece not falling down for 5 minutes. Won’t bring about equipment damaged, etc Safe accidents.(EU CE standard for 5 minutes);
Operating Temperatures range: 32° to 104 °F(0°to 40 °)
Operating time: 8h
-
Service Life: This lifter is designed to have a service life of at least 20,000 lifting
cycles, when used and maintained as intended. Vacuum pads, filter
elements and other wear-out items are excluded, see maintenance
The design of vacuum lifter by our company is passed to EU CE 13155 passed. It is CE identification Product.
