Sheet metal lifting 2016 New product /Electrical Vacuum lifter /Vacuum lifter( surface is smooth, even, No air permeability)
The Vacuum lifter can be combined and operated with many different carrier facilities,such as crane,excavatos, wheel loaders, fork lifts.
Crane+ hoist+vacuum lifter
1. The model No.:BLB2000-18-T
Apply the AL sheet for horizontal handling various panel length less than 10m, To processing the sheet metal in the workshop.
The sheet metal specification as below.
within (1500-10000mm)Lx(1000-2000mm)Wx (1.5 -6)
Maximum weight: 200kg-2000kg
The Sheet temperature 200-250℃ degrees
2. Our equipment describtion:
1.Maximum carrying capacity 2000kg
2. The length of main beam is 9000mm. length of cross beam is 1000mm.
3.The vacuum pump,valve, switch and some important spare parts we are import from oversea.
4. Stable performance, Easy to maintain, Efficient, safe, quick, easy.
5. The suction pad can be adjustable, can be turned off and open individuallly.
6. The vacuum lifter is equipped with a buzzer and warning light units, in case of a power failure or vacuum leakage, an optical and an acoustic signal goes off immediately to warn the operator to do emergency operation.
7. The vacuum lifter is equipped with safety tank&Pressure switch warning, when the power is turned off in sudden, always can keep the workpiece not falling down for 5 minutes. Won’t bring about equipment damaged, etc Safe accidents.(EU CE standard for 5 minutes);
8. The design of vacuum lifter by our company is passed to EU CE 13155 passed.
It is CE identification Product.
3. Application:
Steel boards
Aluminum boards
Plastic boards
Stone slabs
wood panel
Laminated chipboards
4. Load Movement:
- Only Horizontal handling
5. The equipment drawing:
6. The object photos:
