Capacity 10T Vacuum Lifter for Board
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
HeroLift
Model Number:
HL10000-10-T
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shanghai, China
Brand Name
HeroLift
Model Number
HL10000-10-T
Power(W)
0.37kw
Certification
CE ISO9001
Warranty
12 Months
Vacuum lifter horizontal handling
Description:
Designd for use with a crane or other hoisting equipement, vacuum lifter employs vacuum to hold a load for lifting.
Power Source:
See serial number plate for special voltage, frequency and amperage
Function :
1. Max.Capacity 10T
2. Acoustic warning
3. Intergrated safety tank
4. Imported Pump&Valve
5. Efficient,safe,quick, easy
6. safety Tank&Pressure swicth warning
7. Adjustable suction cups, can be turned off individually
Appliaction
Steel plate handling,
plate Un/Loading,
Aluminum Handling,
Alloy Plate Handling
In shipyards
In aircraft industry
For heavy loads with inherent stability
| Load kg | Type | Dim. of suction cup mm | Number of suction cup | Vacuum control | vacuum pump |
power V/FR./PH. |
Own weight | Overall of machine mm L*W*H |
| 2500 | HL2500-10 | Φ360 | 10 | manual/electric | VT4.16 | 380/50^60/3 | 500 | 4000X1000X1200 |
| 3000 | HL3000-3 | 450X850 | 3 | manual/electric | VT4.16 | 380/50^60/3 | 600 | 4000X1000X1200 |
| 4000 | HL4000-4 | 450X850 | 4 | manual/electric | VT4.16 | 380/50^60/3 | 780 | 4500X1000X1200 |
| 4500 | HL4500-18 | Φ360 | 18 | manual/electric | VT4/25 | 380/50^60/3 | 1020 | 5000X1000X1200 |
| 5000 | HL5000-5 | 450X850 | 5 | manual/electric | VT4.25 | 140 | 4500X1000X1200 | |
| 6000 | HL6000-6 | 450X850 | 6 | manual/electric | VT4.40 | 380/50^60/3 | 180 | 6000X1200X1200 |
| 8000 | HL8000-8 | 450X850 | 8 | manual/electric | R0063 | 380/50^60/3 | 250 | 9000X1200X1200 |
| 10000 | HL10000-10 | 450X850 | 10 | manual/electric | R0100 | 380/50^60/3 | 250 | 12000X1200X1200 |
| 15000 | HL15000-10 | 650X850 | 10 | macual/electric | R0160 | 380/50^60/3 | 250 | 12000X1200X1200 |
