Centronics PCB Right Angle Female Socket Connector with Jack Screw
- 1000000 Piece / Pieces per Month
- SHENZHEN / GUANGZHOU
- T/T Credit Card PayPal
You May Like
-
2.16mm pitch Female Telecom Connector PCB Mount Right Angle
-
57CN Centronic Connector Right Angle PCB 2.16mm Pitch Female Header
-
57 Series PCB Right Angle Solder Termination Centronics Connector Female Receptacle Type
-
DDK DIP Female Right Angle PCB Mounting Receptacle Type Centronics Connector Reversed Direction
-
DDK DIP Female PCB Mount Right Angle Centronics Connector 20 Type Receptacle
-
Female Socket Centronics Connector PCB Mounting Right Angle
Product Details
| Place of Origin | Guangdong, China | Brand Name | FUYCONN | |
| Model Number | FUY57009 | Type | Other, Centronic Connector, Right Angle PCB Connector | |
| Application | PCB | Gender | Other, Female, Female Receptacle |
Product Description
Specifications
Item No.: FUY570091,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample
Specifications
1) Product features
1. Product Type: Connector
2. Product Line:CENTRONIC
3. Connector Style: Female
4. Certerline :2.16mm(0.85 in)
5. Number of Position:14,24, 36,50 pin
6. Contact Material: Copper Alloy
7. Contact Plating: Gold (A:5u" ,B:10u",C:15u"A:30u'')
8. Comb Material:Thermoplastic
9. UL Flammability Rating: UL-94-V0
10. Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel
11. Orientation: Reverse
12. Special Function:
A: Screw Lock
B:Rivet Insert
c:4.8mm Hex Screw Lock
D: IEEE488 Hex Screw Lock
2) Electrical Specifications
1. Current Rating: 5Amp
2. Voltage rating: DC 1000v per minute
3. Insulator Resistance: 1000Mn MIN.(at 500V DC)
4. Operation Temperature: -55°C to +105°C
3) Order Information
Remark : 1. This is general information for each of order.
2. Plz reference to filling out this form before inquiry.
3. We will feedback the latest information to you on time.
4. We are look forwar to long term business cooperation with you.
4)Application
| 1, VDSL Telecom Equipment | |
| 2, Computer Peripherals | |
| 3, Communication Equipment | |
| 4, PCB Board | |
| 5, Cable to Panel | |
| 6, Cable to cable | |
| 7,Computer terminal | |
| 8,Telemetering | |
| 9,Test Equipment | |
| 10, Printer |
5) Technology Parameters
