2.16mm pitch Female Telecom Connector PCB Mount Right Angle

Specifications

Item No.: FUY57008
1,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample

Specifications



1) Product features



1. Product Type: Connector

2. Product Line:CENTRONIC

3. Connector Style: Female

4. Certerline :2.16mm(0.85 in)

5. Number of Position:14,24, 36,50,64 pin

6. Contact Material: Copper Alloy

7. Contact Plating: Gold (A:5u" ,B:10u",C:15u"A:30u'')

8. Comb Material:Thermoplastic

9. UL Flammability Rating: UL-94-V0

10. Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel

11. Orientation: Reverse

12. Special Function:

  A: Screw Lock

  B:Rivet Insert

  c:4.8mm Hex Screw Lock

  D: IEEE488 Hex Screw Lock



2) Electrical Specifications



1. Current Rating: 5Amp
2. Voltage rating: DC 1000v per minute
3. Insulator Resistance: 1000Mn MIN.(at 500V DC)
4. Operation Temperature: -55°C to +105°C



3) Order Information





 Remark : 1. This is general information for each of order.

                 2. Plz reference to filling out this form before inquiry.

                 3. We will feedback the latest information to you on time.

                 4. We are look forwar to long term business cooperation with you.



4)Application
