In order to have good cooperation ,we will send free sample to client for testing first!
For photosensitive resistor in our factory,we have many series,the best price and the best service .Quality also is excellent !
LIGHT DEPENDENT RESISTOR
SPECIFICATION AND PERFORMANCE
| Model | Vmax (VDC) | Pmax (mW) | Ambient temp(°C) | Spectral peak (nm) | Light Resistance at 10Lux (KΩ) | Dark Resistance (MΩ) | Gamma value at 100-10Lux | Response Time (ms) | ||||
| Rise Time | Decaytime | |||||||||||
| LD40A0510 | 150 | 50 | -30~+70 | 550 | 5-10 | 0.5 | 0.6 | 20 | 30 | |||
Measuring Conditions
1. Light resistance:
Measured at 10 Lux with standard light A (2854K color temperature) and 2hr illumination at 400-600 lux prior to testing.
2. Dark Resistance:
Measured 10 senconds after closed 10 lux.
3. Gamma Characteristic:
Between 10 lux ande 100 lux and given by
γ = lg(R10/R100)
R10,R100 Cell resistance at 10 lux and 100 lux.
The error of γ is ± 0.1.
4. Pmax:
Max. power dissipation at ambient temperature of 25 °C.
5. Vmax:
Max. voltage in darkness that may be applied to the cell continuously.
