Help CenterControl Board for Galvo Scanner With High Performance
Related Products
-
The Galvo Scanner Control BoardNegotiableMOQ: 1 Piece -
Driver Card for IPG SystemNegotiableMOQ: 1 Piece
-
Laser Marking BoardNegotiableMOQ: 1 Piece
-
Laser Marking Control Board With Software for IPG YLPsystemNegotiableMOQ: 1 Piece
-
Laser Marking Control Board With EzCAD Software for IPG YLP SystemNegotiableMOQ: 1 Piece
Specifications
1.Fast response times and short execution cycle times2.Suitable for high performance applications
SINO-OPER EzCad Card enables real-time control of scan system and lasers over a standard USB host interface.
Customers can integrate complete machinery easily over the EzCad Card due to its compactness and I/O capabilities.
Fast response times and short execution cycle times make the EzCad Card perfectly suitable for high performance applications.
Farther more the EzCad Card can load marking file via a removable MMC memory card.
USB 2.0 micro controller on board
• 128 Kbyte program and data memory
• 64 Kbyte SRAM for USB data buffering
• Real-time calculation of laser and scanner signals
• Online grid correction with 10 us cycle time
• MMC memory card interface
Laser control
• Laser signals for YAG FIBER and CO2 laser types
• opt coupler TTL Level /10 mA output current
• 2 x 8-bit analog channels with 2.5, 5, 10 V output range
• 1 x 8-bit TTL output port
Scanner control
• X, Y channel
• XY2-100 digital interface
Response Times
• The card can response external trigger with in 12ms
• External trigger delay can be adjusted
I/O Port
• 6 Input Port
• 6 Output Port
Power
• +5V/1.5A or +12/0.6A
Packing:
Control Board for Laser Marking will be packed in the wooden case or carton case.
Shipping:
1.Door to door, by the DHL,EMS, UPS,FedEx etc.
2.By air to the Air cargo or by sea to the seaport
1. 1 year warranty.
2. Professional technician support on all our products.
3. We supply the sample,user manual, video operation.
4. Online trade-manager 24 hours.
we will continue to “quality first,customer first” principle of service, to update ,better product and quality service to customers.
About us:
SINO-OPER just is a growing friend with you, and always concentrates on innovative laser scanning systems.
We are honored that our company is supported by the people who are working for it.
Reaching a goal requires a flexible, powerful, dynamic team that reacts on work together as one unit.
Contact us:
grace.cao65
grace.c AT
+86-010-82790570
1.Minimum order quantity:1set
2.Payment terms: T/T in advance, western union
3.Delivery time: within 5 days after payment
4.Warranty: 1year
