12 volt dc motor Performance Introduction:
1. It can be opened and closed with manual/Remote control /anti-theft features without power.
2. The machine structure is compact and delicate, good appearance.
3. The motor is running smoothly and not to be heated easily.
4. The roller shutter motor and main machine have the power cord for equipment only.
The failure rate is low, repairing door without removing the motor.
5. Operating by mechanical limit , it is safe and reliable. The movement form up and down is being controlled automatically the limit switch.
6. It can be used still smoothly with instable voltage and power off.
7. The big character for the AC/DC-24V roller shutter motor: the roller shutter motor can be opened and closed normally when the battery is broken but with power on status.
8.Standard:CCC ,CE
24V DC motor For Roller shutter door Specifications:
Battery voltage: 12V × 2
Current: 10A
Battery capacity: 4.5AH
Maximum hoist torque : 168N.M
MODEL NO. |
Max upgrade |
Max elevating |
Power |
Current Rating |
Output Torque |
Rotation |
Chain No. |
Battery voltage: 12V × 2 | |||||||
AC-DC300 |
6.5 |
300 |
180 |
3.9 |
168 |
5.7 |
10A |
AC-DC500 |
6.5 |
500 |
200 |
3.9 |
343 |
5.7 |
10A |
AC-DC600 |
6.5 |
600 |
250 |
3.9 |
412 |
5.7 |
10A |
Forchance Factory view:
Usuage of the 24V DC motor Of Rolling Shutter door:
Bracket and Accessories for roller shutter door motor:
100% Testing before shipment to make sure the quality:
- Durable - Reliable - Low maintenance Brushless dc motor ,
Welcome to inquiry !
