Non-isolated Constant Current Internal LED Driver

Name: Non-isolated Constant Current Internal LED Driver
Brand: EVADA
SKU: 113484953
Availability: InStock

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

EVADA

Model Number:

CUF-100-070-FGL

Xiamen Evada Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name EVADA

Model Number CUF-100-070-FGL

Output Power 51 - 100W

Output Type Single

Input Voltage 220V

Output Voltage 40-142V

Output Frequency 50Hz

Output Current 700mA

Non-isolated Constant Current Internal LED Driver

MODEL		CUF-100-070-FGL
OUTPUT	DC VOLTAGE	40-142V
	CONSTANT CURRENT REGION	40-142VDC
	RATED CURRENT	700mA
	RATED POWER	100W
	RIPPLE & NOISE	±4%
	VOLTAGE TOLERANCE	10%
	LOAD REGULATION	±2.0%
INPUT	VOLTAGE RANGE	90~264VAC
	FREQUENCY RANGE	47~63Hz
	POWER FACTOR	PF≥0.95/220VAC
	EFFICIENCY(Typ.)	88%
	AC CURRENT	0.65A Max
PROTECTION	OVER CURRENT	±5% rated output current
	OVER CURRENT	Protection type: Constant current limiting
	SHORT CIRCUIT	Hiccup mode
		Protection type: Shut down and latch off o/p voltage, re-power on to recover.
	Over temperature	Protection type: Shut down o/p voltage, re-power on to recover.
ENVIRONMENT	WORKING TEMP.	-30°C~+70°C
	WORKING HUMIDITY	10%RH~100%RH non-condensing
	STORAGE TEMP., HUMIDITY	-40°C~+80°C
SAFETY& EMC	SAFETY STANDARDS	IEC/EN60598;IEC/EN61347;CB
	WITHSTAND VOLTAGE	I/P-O/P:3KVAC
	EMC	EN55015/EN61547/EN61000
OTHERS	IP RATING
	MTBF	60000Hours
	DIMENSION	1504028mm(LWH)
	PACKING	0.2KG/pc
