9W Ip20 Led Driver Small Drivers
Negotiable
MOQ: 500 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Evada
Model Number:
CHF-009-017
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
7w Led Driver Constant Current 150ma Led DriverNegotiableMOQ: 500 Units -
7w 5w Led Driver 150maNegotiableMOQ: 500 Units
-
IP20 300mA Led Driver Constant Current 10w LED DriverNegotiableMOQ: 500 Units
-
Led Driver Wholesale Small Led Driver 32w Led DriverNegotiableMOQ: 500 Units
-
500ma Led Driver Plastic Case IP40 16w Power Supply Plastic CaseNegotiableMOQ: 500 Units
Place of Origin
Fujian, China
Brand Name
Evada
Model Number
CHF-009-017
Output Power
Other, 9W
Output Type
Single
Input Voltage
Other, 30V-55VDC
Output Voltage
55V
Output Frequency
50Hz/60Hz
Output Current
175mA
Product Description
ip20 led driver 9W small drivers
| Features : | |||
| 1.Hight input voltage (176VACup to 264VAC) | |||
| 2.Protections: Overload / Over voltage /short circuit | |||
| 3.Cooling by free air convection | |||
| 4.Suitable for LED lighting | |||
| 5.IP20 design | |||
| 6.3 years warranty |
Specification
| MODEL | CUF-009-017 | |||||||||
| OUTPUT | DC VOLTAGE | 55VDC | ||||||||
| CONSTANT CURRENT REGION | 30-55V | |||||||||
| RATED CURRENT | 175mA | |||||||||
| RATED POWER | 9W | |||||||||
| RIPPLE & NOISE (max.) | 2000mVp-p | |||||||||
| LINE REGULATION | ±3% | |||||||||
| LOAD REGULATION | ±3% | |||||||||
| SETUP, RISE TIME | 200/80ms at full load 220VAC /176VAC | |||||||||
| INPUT | VOLTAGE RANGE | 176-264VAC | ||||||||
| FREQUENCY RANGE | 47-63Hz | |||||||||
| EFFICIENCY (Typ.230Vac/50Hz) | ≥85% | |||||||||
| AC CURRENT | 60mA / 176VAC | |||||||||
| INRUSH CURRENT(max.) | COLD START 5A/250VAC | |||||||||
| PROTECTION | OVER CURRENT (Typ.) | 95 - 108% | ||||||||
| Protection type : Constant current limiting, recovers automatically after fault condition is removed | ||||||||||
| OVER VOLTAGE | 60-65V | |||||||||
| Protection type : Constant voltage limiting | ||||||||||
| ENVIRONMENT | WORKING TEMP. | -30 ~ +55℃ @ full load ; +70℃ @ 60% load | ||||||||
| WORKING HUMIDITY | 20-95% RH non-condensing | |||||||||
| STORAGE TEMP., HUMIDITY | -40~ +80℃, 10 ~95% RH | |||||||||
| TEMP. COEFFICIENT | ±0.03%/℃(0-50℃) | |||||||||
| VIBRATION | 10 - 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes | |||||||||
| SAFETY & EMC | SAFETY STANDARDS | UL1012 ; EN61347-1, EN61347-2-13 independent ; UL60950-1, TUV EN60950-1 (TBD) | ||||||||
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC | |||||||||
| SOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 ℃/ 70% RH | |||||||||
| EMI CONDUCTION & RADIATION | Compliance to EN55015, EN55022 (CISPR22) Class B | |||||||||
| HARMONIC CURRENT | Compliance to EN61000-3-2 Class C (≥75% load) ; EN61000-3-3 | |||||||||
| EMS IMMUNITY | Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN61547, EN55024, light industry level (surge 4KV), criteria A | |||||||||
| OTHERS | MTBF | 30Khours. | ||||||||
| DIMENSION | L60*W14*H10.6mm | |||||||||
| NOTE | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. | |||||||||
| 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. | ||||||||||
3. Constant current operation region is within 75% ~100% rated output voltage. This is the suitable operation region for LED related applications, but please reconfirm special electrical requirements for some specific system design. 4. Safety and EMC design refer to EN60598-1, subject 8750(UL), CNS15233, GB7000.1, FCC part18. | ||||||||||
ip20 led driver
Series Recommend
Packaging & Shipping
9W ip20 led driver small drivers
