0-10v Dimming Led Driver 45w Dimmable Led Driver 320ma Led Power Supply

Descriptions

1. Resistive dimming – 100K potentiometer, variable resistance across the internal control voltage from a driver therefore does not require an external voltage.

2. PWM Signal dimming – PWM is also known as pulse width modulation; this is where an external circuit is used to control the average voltage to the dimming input.

We offer a dimmable power supply range with 2-in-1 dimming – This combines the types of dimming, PWM and resistive dimming.

Features

1. PWM+Resistor dimming mode.
2. Isolated and 2 stages circuit.
3. Built in active PFC function, power factor: ≥0.98
4. Dimmed by potentiometer, easily operated.
5. Typical DC Current: 200-470mA adjustable, DC  voltage: 65-100Vdc(can be custom-made).
6. Current can be adjustable by your need through potentiometer.
7. Plastic case, IP40.
8. Input and output with terminal blocks.
9. Widely used for LED Panel Lights.
10. Zero ripple of current, high efficiency, energy-saving and eco-friendly.
11. Built in test: 100% for at least 4 hours under environment temperature of 40 degree
12. Warranty: two years.
13. DC Voltage and DC current can be customized.
14. Supply ability: 50000pcs/ month.
