Specifications
1, IEC, ASTM, DIN, BS VDE, UL, GOST,SAS standard.2, ISO, CCC, CQC certification approved. 8 Years Experience of OEM service.
Aluminum Rod
Specifications
l It is mainly used for drawing the core of wires and cables
l The surface of the rod is clean, smooth and seamless.
l Coil weight: large coil 1000kg, small coil: 300--1000kg
Aluminum Rod was produced and provided by consulting and following the American standard ASTM B233 and Germany standard EN17152
1.Producing and providing the products according to Chinese standard GB/T3954-2001, and consulting and following the American standard ASTM B233:1997, and Germany DIN standard EN 17152:1997
2.The Type,Condition and Range
Type |
Condition |
Range(mm) |
A |
o |
Φ9-20 |
A2,A4,A6,A8 |
H/R |
3.The Mechanics and Electric Function
Type |
Tensile Strength (M pa) |
Percentage Elongation (%≥) |
Resistivity at 20°c (nΩ.m≤) |
A |
60-80 |
25 |
27.55 |
A2 |
80-100 |
12 |
27.85 |
A4 |
95-115 |
10 |
28.01 |
A6 |
110-130 |
8 |
28.01 |
A8 |
120-150 |
6 |
28.01 |
4.The Component of Material
Name of Element |
Si |
Fe |
Cu |
V+Ti+Mn+Cr |
Other |
Al |
Percentage % |
≤0.11 |
0.25 |
0.01 |
0.02 |
0.03 |
≥ 99.61 |
5.Standard specification for Aluminum 1350 Drawing Stock for Electrical Purposes
TABLE 1- Tensile Property Limits
Temper |
Tensile Strength |
|
|
Ks j |
M pa |
1350-O |
8.5-14.0 |
59-97 |
1350-H12 and-H22 |
12.0-17.0 |
83-117 |
1350-H14 and-H24 |
15.0-20.0 |
103-138 |
1350-H16 and-H26 |
17.0-22.0 |
117-152 |
TABLE 2- Electrical Resistivity Limits
Temper |
Resistivity |
Equivalent Volume Conductivity,% |
|
Max.Ω.mm2/m |
IACS Min. |
1350-O |
0.027899 |
61.8 |
1350-H12 and-H22 |
0.028035 |
61.5 |
1350-H14 and-H24 |
0.028080 |
61.4 |
1350-H16 and-H26 |
0.028126 |
61.3 |
