Good Quality Computerized Collar Knitting Machine 868BG

Name: Good Quality Computerized Collar Knitting Machine 868BG
Brand: LONGTEX
SKU: 113376091

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Product Type:

Collar

Type:

Jacquard

Yantai Longyu Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO OR SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Product Type Collar

Type Jacquard

Place of Origin Zhejiang, China

Brand Name LONGTEX

Model Number 61BG

Knitting Style Flat

Knitting Method Single

Computerized Yes

Weight 565kgs

After-sales Service Provided Engineers available to service machinery overseas

collar knitting machine
computerized collar machine 61BG

Type	LONGTEX-61BG
Breadtn	52"
Gauge	5G, 7G, 9G, 12G, 14G
Knitting speed	Controlled by frenquency conversion to adjust speed, 6 grade speed, Max. Speed: 1.2m/sec
Needle bed movement	About 2 inch of the needle bed movement range, 1/2 needle can be moved in any position
Transfer	The action can be done through front and back, and separate needle to knit
Knitting needle type	Upper lower foot transfer needle and upper lower foot needle foot
Stitch	Step motor 150 levels program instruction adjust, 8-group stitch
Main function and feature	This kind of machine adopts computer program control, mainly uses in material, such as cotton, flax, silk, wooden, polyester fiber, blending fabric to realize auto knit of the woolen sweater and clothing appendix. And also have function of auto 6-yarn change, auto ajust stitch, auto needle bed movement, auto stop machine when trouble occurred etc.
Transmission mode	Synchronous belt moves bacn and forth, can freely adjust working width
Control mode	Controlled by computer program. LCD large screens display
Power	AC220V±8% 50HZ 0.3KVA
Packing size	2250X800X1900mm
Gross weight	515kg
Net weight	565kg
