4 Channel Class D PRO Qsn Audio Power Amplifiers Fp10000Q
Parameters:
Channel number: 4CH
8Ohm stereo, 1350W
4Ohm stereo, 2100W
2Ohm stereo, 2500W
8Ohm bridge: 4200W
4Ohm bridge: 5000W
Gain: 35dB VPL:101V
THD+N: <0.1%
THD: <0.05%
S/N ratio: >112dB
Crossover: >70dB
Frequency: 6.8Hz-34KHz
Input impedance: 20Kohm
Gain selecrable: 23,26,32,35,38,41,44dB
Input connector: XLR
Output connector: Neutrik speakon
output bridge modeL A+B-CH: A is input source, A+B, C+D -CH: A,C is input source
Cooling: 2 fans, front to rear airflow, temperature control
Size: 483*88*398mm
weight: 15kgs
outlook: black painted chassis, with black painted steel front
| MODEL | FP-10000Q | FP-8000Q |
| Output Power | 20-20kHz, 1W with 1 khz | 20-20kHz, 1W with 1 khz |
| 8ΩStereo Power(RMS) | 1350WX4 | 800WX4 |
| 4ΩStereo Power(RMS) | 2100WX4 | 1400WX4 |
| 2ΩStereo Power(RMS) | 2500WX4 | 1600WX4 |
| 8ΩBridged Power(RMS) | 4200WX2 | 2800WX2 |
| 4ΩBridged Power(RMS) | 5000WX2 | 3200WX4 |
| Frequency Response(+o/-0.3dB,1W/8Ω) | 20 Hz - 34 kHz | |
| THD 20 Hz - 20 kHz for 1 W | <0.1% | |
| Signal-to-Noise Ratio | >112 dBA | |
| Channel separation (Crosstalk) at 1 kHz | >70 dB | |
| Input Connectors (per channel) | 3-pin XLR, electronically balanced | |
| Output Connectors (per channel) | Binding Posts 2-pole | |
| Class | TD | |
| TourClass Protection | ACL,IGM,AutoRamp,short cricuit,DC voltage,turn-on/off transient,current,inrush | |
| Operating voltage | 130-265 V / 65-135 V selectable | |
| Voltage Gain(dB) | 23, 26, 29, 32, 35, 38, 41, 44 dB selectable | |
| Input impedance | 20 kOhm | |
| Level adjustment (per ch.) | Front-panel potentiometer, 31 position detented from -inf to 0 dB | |
| Dimensions (W×H×D) | 483×88×396mm | |
| Packing dimension | 560×180×500mm | |
| Net weight(kg) | 12 | 12 |
| Gross weight(kg) | 15 |
15 |
Professional speaker and line array speaker,subwoofer speaker package details:
Mini Line array ATA case/Flight case package:
Professional speaker and line array speaker,subwoofer flight case package details:
Power amplifier inside package details:
Power amplifier outlook package in store details:(a plastic bag encase the amplifier to waterproof)
