Product Description
Sales Promotion 500W*2 Power amplifier
1)Adopting SMT technology.It looks on top grade
2)Switching power supply technology is used in power supply to lower the power consumption
3)XLR cannon and terminal block output to make machine more stability
4)With 50HZ /30HZ low cut and channel clipping selector switch
5)It has stereo,bridge and merge output ,Easy operation of function bill in the back side
6)There is a independent protection, clip, signal instruction, so it can monitor the working status of each channel easily.
7)It has overtemperature protection, current protection, short circuit protection
8)built in intelligent limiter system,It can detect output signal is distortion or not.when the distortion is more than 0.5%, the machine will turn into a limiter circuit situation, then reducing the output level to ensure that the amplifier output signal within a certain range will not be clipping, to avoid damage to the speaker unit
9)The amplifier can be 2 ohm mode
700W*2 8 ohm
1100W*2 4 ohm
1500W*2 2 ohm.
Bridge output power is 2000W 8 ohm
Bridge output power is 3000W 4 ohm
Voltage can be 90V~240V
Net weight is 11Kg for Q-7 700W and 10.5Kg for Q-5 500W.
Gross weight is 14Kg.
Size is 483*380*88.8mm
| Model | Q7 | Q5 |
| Power 8Ω | 700W×2 | 500W×2 |
| Power 4Ω | 1100W×2 | 800W×2 |
| Power 2Ω | 1500W×2 | 1200W×2 |
| Bridge output power 8Ω | 2000W | 1700W |
| Bridge output power 4Ω | 3000W | 2500W |
| Frequency response | +-0.3dB | +-0.3dB |
| Signal to noise | ≥100dB | ≥100dB |
| Input sensitivity | 0.775V | 0.775V |
| THD | ≤0.05%(1KHz) | ≤0.05%(1KHz) |
| Damping factor | ≥300 | ≥300 |
| Supply power | 3800W | 3300W |
| Net weight | 11KG | 10.5KG |
| Height | 3U | 3U |
| Size(mm) | 484W × 360D × 88H | 484W × 360D × 88H |
| Package size(mm) | 590W × 520D × 145H | 590W × 520D × 145H |
my name is kevin, and my whatsapp is + 86 13794341339
