Factory Direct 1350w 4 Channel Professional High Amplifier

US$ 100 - 1,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

QSN

Model Number:

P10000Q

Guangzhou Yunqiang Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name QSN

Model Number P10000Q

4 channel switch mode professional high power amplifier FP10000Q

1.Brand new high efficiency techonology of the new TD class product.

2.ultra-high-power switching regulator power supply,high energy storage capacity,high density,full power and domineering.

3.highly load output capablity with work effiency.

4.integrated intelligent protection,while output with heavy loading freely.

5.performance excellent,including new generation of power supply amplifier product.

MODEL	FP10000Q
Output Power	20-20kHz, 1W with 1 khz
8ΩStereo Power(RMS)	1300WX4
4ΩStereo Power(RMS)	2100WX4
2ΩStereo Power(RMS)	2500WX4
8ΩBridged Power(RMS)	4200WX2
4ΩBridged Power(RMS)	5000WX2
Frequency Response(+o/-0.3dB,1W/8Ω)	20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W	<0.1%
Signal-to-Noise Ratio	>112 dBA
Channel separation (Crosstalk) at 1 kHz	>70 dB
Input Connectors (per channel)	3-pin XLR, electronically balanced
Output Connectors (per channel)	Binding Posts 2-pole
Class	TD
TourClass Protection	ACL,IGM,AutoRamp,short cricuit,DC voltage,turn-on/off transient,current,inrush
Operating voltage	130-265 V / 65-135 V selectable
Voltage Gain(dB)	23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance	20 kOhm
Level adjustment (per ch.)	Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)	483×88×396mm
Packing dimension	560×180×500mm
Net weight(kg)	13
Gross weight(kg)	16
